FCD-IPM Installation and Operation Manual Chapter 5 Setup Menu
Interface Parameters Menu 5-35
• When CRC-4 is enabled, diagnostics are available for the last 24 hours
collected in 15-minute intervals (similar to the AT&T PUB 54016).
T1 Setup Menu
T1 SETUP: LINK 1 (Device name - FCD-IPM)
----------------
1. Clock master : [Link 1]
2. Multiplier : [64 kbps]
3. Time slots mapping
4. General Diagnostics
5. T1 parameters
6. Additional Cards parameters
7. Alarms filter
8. Advanced Setup
ESC - Return to previous menu
Figure 5-41. T1 Setup Menu
Table 5-17. T1 Setup Parameters
Parameters Possible Values Description
Clock Master
Internal
Link 1
I/O1 SUB T1
I/O2 SUB T1
FIX SUB T1
Selects the source clock that synchronizes the whole T1
network
FCD-IPM generates the system source clock from an internal
clock oscillator.
FCD-IPM recovers the clock from the data received from the
T1 link1
For FCD-IPM with a sublink:
FCD-IPM recovers the clock from the data received from one
of the T1 sublinks
Multiplier
56 kbps, 64 kbps
Sets the data rate of each DATA time slot.
