FCD-IPM Installation and Operation Manual Chapter 5 Setup Menu
Interface Parameters Menu 5-51
E1 Setup Menu
This section describes the parameters in the E1 Setup menu.
E1 Setup: LINK 1 (Device name – FCD-IPM)
------------------
1. Clock Master: [Link 1]
2. Multiplier : [64 kbps]
3. Time slots mapping
4. General Diagnostics
5. E1 parameters
6. Additional Cards parameters
7. Alarms filter
8. Advanced Setup
ESC – Return to previous menu
Choose one of the above:
Figure 5-56. E1 Setup Menu
Table 5-19. E1 Setup Parameters
Parameters Possible Values Description
Clock Master
Internal
Link 1
I/O1 SUB E1
I/O2 SUB E1
FIX SUB E1
Selects the source clock that synchronizes the whole E1
network
FCD-IPM generates the system source clock from an internal
clock oscillator.
FCD-IPM recovers the clock from the data received from the
E1 link1
For FCD-IPM with a sublink
FCD-IPM recovers the clock from the data received from one
of the E1 sublinks
Multiplier
56 kbps, 64 kbps
Sets the data rate of each DATA time slot.
