Chapter 5 Setup Menu FCD-IPM Installation and Operation Manual
5-64 Interface Parameters Menu
E1 TIME SLOTS MAPPING: LINK1 (Device name – FCD-IPM)
---------------------
TS1 [DATA LINK1] TS17 [NC]
TS2 [DATA LINK1] TS18 [NC]
TS3 [NC] TS19 [NC]
TS4 [NC] TS20 [NC]
TS5 [FIX SUB-VOICE] TS21 [NC]
TS6 [FIX SUB-VOICE] TS22 [NC]
TS7 [FIX SUB-DATA] TS23 [NC]
TS8 [NC] TS24 [NC]
TS9 [NC] TS25 [NC]
TS10 [NC] TS26 [NC]
TS11 [NC] TS27 [NC]
TS12 [NC] TS28 [NC]
TS13 [NC] TS29 [I/O2 VOICE 1]
TS14 [I/O1 VOICE 1] TS30 [I/O2 VOICE 4]
TS15 [I/O1 VOICE 2] TS31 [NC]
TS16 [NC]
Enter time slot number (0 refer to all time slots)
Press ‘ENTER’ – to toggle the time slot type
Press ‘ESC’ - to Return to previous menu
Time slot number: 5
Figure 5-67. E1 Time Slots Mapping Link1 Screen
Alarms Filter
The Alarm Log File shows all events and alarm statuses that have occurred in the
E1/T1 interface. You can use the Alarm Filter to mask or unmask events from the
Alarm Log File.
