FCD-IPM Installation and Operation Manual Chapter 5 Setup Menu
Access Control (Security) Menu 5-77
Security Host/Guest (PPP only)
SECURITY HOST/GUEST ( Device name - FCD-IPM )
1. Security for LINK 1 : [HOST ]
2. Security for LINK 2 : [HOST ]
Press the number to edit value or ESC to return to the previous screen:
Figure 5-81. Security Host/Guest Menu
Select this parameter to define a link's security status. When a link is defined as a
Host, users are approved according to your profile list. When the link is defined as
a Guest, the device sends its name and password (defined above) to be approved
by the host. The Guest mode is the default for Originate only links. For Answer
and Answer&Originate links the default mode is Host.
Login Script Setup
CURRENT SCRIPT FOR LINK 1 Status: [disable]
------------------------- -------
A - Append, I - Insert, D - Delete, E - Edit, C - Clear all
N - Next screen, P - Previous screen, S - Status change
ESC - return to previous menu
Choose one of the above:
Figure 5-82. Script Setup Menu
The FCD-IPM scripting tool allows you to negotiate an initial login, required by
some ISPs. The initial login usually consists of a username, password and possibly
additional information which has to be entered to gain access to the ISP.
Advanced Menu
↓1
Setup Menu
↓4
Access Control (Security)
↓3
Security Host/Guest Menu
Advanced Menu
↓1
Setup Menu
↓4
Access Control (Security)
↓4
Script Setup Menu
