FCD-IPM Installation and Operation Manual Chapter 5 Setup Menu
WAN Economy Menu 5-81
WAN ECONOMY (Device name - FCD-IPM)
-----------
Use these features:
- to reduce traffic over the WAN to a minimum and increase throughput
- to keep the link up only when it is required
1. Filters
2. Connection on demand
3. Spoofing
ESC - Return to previous menu
Choose one of the above:
Figure 5-84. WAN Economy Menu
The options in the WAN Economy menu are described below.
Filters
FILTERS ( Device name – FCD-IPM )
-------
1. Block and Forwarding
2. IP / IPX broadcast control - [Block Propagation]
3. Quick filters
4. Advanced filters
Esc - Return to main menu
Choose one of the above:
Figure 5-85. Filters Menu
Filtering allows you to limit the amount of traffic that enters and exits the Small
Office LAN via FCD-IPM. If FCD-IPM is attached to more than one LAN, then
select this option for each LAN interface. Filtering is used to:
• Increase security
• Reduce traffic to the link.
Advanced Menu
↓1
Setup Menu
↓5
WAN Economy Menu
↓1
Filters Menu
