Chapter 5 Setup Menu FCD-IPM Installation and Operation Manual
5-90 WAN Economy Menu
To exit filtering and return to the main Setup menu, press <Esc>. The following
prompt appears: 'up' (Y/N)?
Press Y to save changes in the Flash Memory. Press N to cancel your changes. The
system loads the previous set of masks the next time the system is rebooted.
Connection on Demand
Connection On Demand (Device name - FCD-IPM)
--------------------
1. Start Connection
2. Terminate Connection
3. Minimum Time Between Two Connects
4. Minimum Time Between Two Disconnects
5. Connect Manually
6. Disconnect Manually
ESC - Return to previous menu
Choose one of the above:
Figure 5-91. Connection On Demand Menu
To save money, you may want to limit the time that a link is kept open. COD
allows you to determine the traffic conditions that open and close the link. Using
COD, a line is opened only when traffic conditions fulfill specified conditions.
When there is no need for a connection, the line is automatically terminated.
COD is only effective if:
• The line is connected to a modem or ISDN (a dialup link)
• The link is asynchronous
• The connection type is Originate or Answer&Originate.
If the connection type is Answer only, the line connection is started when the unit
is turned on in order to receive calls. If the connection type is Originate only or
Answer&Originate the connection starts when a telephone number is defined.
Advanced Menu
↓1
Setup Menu
↓5
WAN Economy Menu
↓2
Connection on Demand
