FCD-IPM Installation and Operation Manual Appendix C SNMP Management
SNMP Configuration C-5
C.2 SNMP Configuration
Indexing Convention
The following is the indexing convention of the SNMP configuration:
• Lan1 ifindex = 1
• Lan2 ifindex = 2
• Link1 ifindex = 3
• Link2 ifindex = 4
• SubE1 ifindex = 5
• Voice1 ifindex = 6
• Voice2 ifindex = 7
• Voice3 ifindex = 8
• Voice4 ifindex = 9.
Other indices are dynamic numbers which indicate higher protocol layers of the
physical interfaces.
The following indices are used for FCD-IPM with E1 over SHDSL interface:
• SHDSL – ifindex = 3
• E1 – dynamic.
Configuration
➤ To access SNMP configuration:
1. Enter Security Setup menu.
2. Choose Device Access Restrictions.
3. Choose SNMP Access Status: Enable/Disable.
Community Configuration
➤ To enable community configuration:
1. Enter Security Setup menu.
2. Choose Device Access Restrictions.
3. Choose either: SNMP Read, Write or Trap Community, depending on what
you want to configure.
4. Configure the community to the same setting as at the NMS station.
Trap Configuration
➤ To enable trap configuration:
1. Enter Advanced Menu.
Note
