FCD-IPM Installation and Operation Manual Chapter 4 Configuration
Quick Setup Menu 4-5
Quick Setup Menu Examples
The following pages illustrate some of the Quick Setup menus, dependent upon
the interface that has been ordered.
Quick Setup for T1 (PPP, IP)
Figure 4-2 shows the Quick Setup menu for T1.
QUICK SETUP
-----------
WARNING: This device automatically exits to Operational
Messages 10 minutes after last keyboard action without
saving parameters
'ENTER' - Accept parameter , 'SPACE' - Change parameter.
WAN interface Link 1 - T1
Link status : [Enable]
Link mode : [Synchronous]
Routing : [IP ROUTER], Protocol: [PPP]
WAN IP address : 10.0.0.1, enter new : 10.0.0.1
WAN IP mask : 255.255.255.252, enter new: 255.255.255.252
Do you want to configure the T1 Interface parameters (Y/N)?:
Host IP setup:
LAN Status : [Enable]
LAN IP address : 192.168.1.1, enter new : 192.168.1.1
LAN IP mask : 255.255.255.000, enter new : 255.255.255.000
Default gateway setting by: [Interface]
Default gateway interface: 1
SECURITY Setup
Device access name : FCD-IPM
No password at present – do you want to create password (Y/N)?: [N]
Security type : [Disabled]
Saving the changes might cause RESET the unit.
Do you want to save QUICK SETUP (Y/N)? Y
Figure 4-2. T1 Interface Quick Setup Screen
