FCD-IPM Installation and Operation Manual Chapter 4 Configuration
Advanced Setup Menu 4-21
Device Control Menu
2
Device Control
1
Advanced Menu
1
Software
Download
1. Download
from TFTP
Server
2. XMODEM via
Control Port (BOOT
Manager)
3
Download Device
Parameters from
TFTP Server
2
Upload Device
Parameters to
TFTP Server
Setup
4
Reset Options
5
Terminal Type
1. Reset Device
2. Reset Link
3. Reset Interface
Module
1. VT-100, VT-200,
VT-220 ANSI
Terminals
2. VT-52, IBM 3101
Terminals
3. Other Terminals
Figure 4-16. Device Control Menu Outline
To access the Device Control menu:
• In the Advanced Menu, press 2.
The Device Control menu appears (refer to Figure 4-17).
DEVICE CONTROL (Device name - FCD-IPM)
--------------
1. Software download
2. Upload device parameters to TFTP server
3. Download device parameters from TFTP server
4. Reset options
5. Terminal type
ESC - Return to previous menu
Choose one of the above:
Figure 4-17. Device Control Menu
The options in the Device Control menu are described below.
