Chapter 4 Configuration FCD-IPM Installation and Operation Manual
4-30 View Menu
Bridge
Select this option to display a table that contains information on Bridge MAC
addresses (see Figure 4-28).
BRIDGE TABLE (Page-1) (Device name - FCD-IPM)
------------
MAC ADDRESS TYPE INTERFACE
----------- ---- ---------
0020D2FD5153 Static or Dynamic LAN
ESC - Return to previous menu
Figure 4-28. Bridge Table
IP Interfaces
Details the routing interfaces information.
IP INTERFACES TABLE (Page-1) ( Device name - FCD-IPM )
-------------------
IP ADDRESS IP MASK MTU PROTOCOL INTERFACE STATUS
--------------- --------------- ----- --------- ---------- ------
192.170.007.001 255.255.255.000 1500 --------- LAN 1 UP
000.000.000.000 000.000.000.000 1500 --------- LINK 1 UP
ESC - Return to previous menu
Figure 4-29. IP Interfaces Table
IP Routing
Select this option to display a table that contains information on IP routing.
IP ROUTE TABLE (Page-1) ( Device name - FCD-IPM )
IP ADDRESS IP MASK TYPE COST NEXT HOP AGEING INTERFACE
------------- --------------- ------ ---- --------------- -------- ----------
default gateway LINK 1
192.170.007.000 255.255.255.000 INTRF 0 192.170.007.001 00:00:00 LAN 1
ESC - Return to previous menu
Figure 4-30. IP Routing Table
