OC-OSB80 32˝ OCTA SOFTBOX FOR RAYA FLUORESCENT FIXTURE 7
INTRODUCTION Thank you for choosing the Raya 32˝ Octa Softbox for Raya Fluorescent Fixture 7. Designed for use with 7 - 50 watt spiral fluorescent bulbs at a maximum of 350 watts, this softbox includes a 32˝ removable front and interior diffusers, making the item ideal for scenarios requiring a soft light spread. This quality softbox is highly portable. With no speed ring required for operation, it is perfect for studio or on-location shooting scenarios that require an easy setup and takedown.
PRECAUTIONS ⚠ ⚡ • Please read and follow these instructions. Keep this manual in a safe place. • Use only spiral fluorescent bulbs. Not for use with household tungsten bulbs. Handle fluorescent bulbs with care. Dispose of fluorescent bulbs properly. Fluorescent bulbs contain mercury. If a fluorescent bulb breaks, do not touch mercury with hands—exposure to mercury can lead to adverse health effects. Keep this product away from water and any flammable gases or liquids.
INSTRUCTIONS ASSEMBLING THE SOFTBOX The Raya 32˝ Octa Softbox is directly compatible for use with the Raya Octa Fluorescent 7 Socket Fixture. Before attaching the two items, make sure all lamps are removed from the fixture and that it is not plugged into a power source. Also remove the fixture from any mounted peripheral. 1 2 4 Remove the softbox from the carrying case and unfold it.
Take a flex rod from the carrying case and insert the black end into one of the eight flex rod slots on the light fixture. 6 Align the softbox’s flex rod pockets with the flex rod slots on the light fixture. Insert the silvertipped end of the flex rod into one of the flex rod pockets on the inside edge of the softbox. Bending the rod may be necessary to fit into the pocket. 7 Attach the next rod on the opposite side from the first rod.
ASSEMBLY INSTRUCTIONS 9 Install the fluorescent bulbs on the light fixture. 10 Install the inner diffuser baffle in the softbox by inserting the baffle’s loops into the softbox’s baffle clips on the inner surface, half way up the side. 6 11 Once secured, take the outer diffuser and stretch it over the open mouth of the softbox. Connect the baffle and diffuser’s touch fasteners to secure. 12 Mount the light fixture on a light stand to complete the setup process.
DISASSEMBLY INSTRUCTIONS bend the rods to remove them from their slots. 1 Turn off the light fixture and disconnect it from the power source. 5 2 Once the bulbs have cooled, take off the front and inner diffusers and carefully remove the bulbs from the light fixture. 6 Fold up the softbox and 3 Remove the light fixture from its stand. 4 Remove the flex rods from the softbox.
ONE-YEAR LIMITED WARRANTY This RAYA product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
