Installation Instructions ArmorPoint 24V DC 16 Point Input and Output Modules, Series A Catalog Numbers 1738-OB16E19M23, 1738-OB16EM12, 1738-OB16E25DS, 1738-IB16DM12 Topic Page Important User Information 2 Environment and Enclosure 3 Prevent Electrostatic Discharge 3 About the Modules 4 Mount the I/O Base 5 Install the Digital Module 7 Remove the Module From the Mounting Base 8 Wire the Modules 8 Communicate with Your Module 10 Specifications 14
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://literature.rockwellautomation.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 3 Environment and Enclosure ATTENTION This equipment is intended for use in overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes up to 2000 meters (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A About the Modules The ArmorPoint I/O family consists of modular I/O modules. The sealed IP67 housing of these modules requires no enclosure when used with IP67 certified cables. (Note that environmental requirements other than IP67 may require an additional appropriate housing.) I/O connectors are sealed DB25, M12 (micro) or M23 styles. The mounting base ships with the module.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 5 Mount the I/O Base To mount the base on a wall or panel, use the screw holes provided in the base. IMPORTANT The module must be mounted on a grounded metal mounting plate or other conductive surface. Refer to the Drilling Dimensions illustration of the base with an adapter to help you mount the base. Drilling Dimensions Adapter 46.25 mm (1.8 in) 51.9 mm (2.0 in) 20.1 mm (0.8 in) 51.9 mm (2.0 in) 20.1 mm (0.8 in) 51.9 mm (2.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A ATTENTION To comply with the CE Low Voltage Directive (LVD), this equipment must be powered from a source compliant with the following: Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV). Install the mounting base as follows: 1. Lay out the required points as shown above in the drilling dimension drawing. 2. Drill the necessary holes for M4 (#8) machine or self-tapping screws. 3. Mount the base using M4 (#8) screws. 4.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 7 Install the Digital Module To install the digital module, proceed as follows: 1. Using a bladed screwdriver, rotate the keyswitch on the mounting base clockwise until the number 1 aligns with the notch in the base. 2. Position the module vertically above the mounting base. The module bridges two bases.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A Remove the Module From the Mounting Base To remove the module from the mounting base: 1. Put a flat blade screwdriver into the slot of the orange latching mechanism. 2. Push the screwdriver toward the I/O module to disengage the latch. The module lifts up off the base. 3. Pull the module off of the base. Wire the Modules Following are wiring instructions for the modules.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 9 1738-OB16EM12 (view into connector) Pin 1 - Not Used Pin 2 - 24V DC output 1 (M12-A) 24V DC output 3 (M12-B) 24V DC output 5 (M12-C) 24V DC output 7 (M12-D) 24V DC output 9 (M12-E) 24V DC output 11 (M12-F) 24V DC output 13 (M12-G) 24V DC output 15 (M12-H) Pin 3 - Common Pin 4 - 24V DC output 0 (M12-A) 24V DC output 2 (M12-B) 24V DC output 4 (M12-C) 24V DC output 6 (M12-D) 24V DC output 8 (M12-E) 24V DC output 10 (M12-F) 24V DC output 12 (M12-G
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 1738-IB16DM12 (view into connector) 43664 ATTENTION Pin 1 - SSV 0 (M12-A,B) SSV 1 (M12-C,D) SSV 2 (M12-E,F) SSV 3 (M12-G,H) Pin 2 - 24V DC input 1 (M12-A) 24V DC input 3 (M12-B) 24V DC input 5 (M12-C) 24V DC input 7 (M12-D) 24V DC input 9 (M12-E) 24V DC input 11 (M12-F) 24V DC input 13 (M12-G) 24V DC input 15 (M12-H) Pin 3 -Common Pin 4 - 24V DC input 0 (M12-A) 24V DC input 2 (M12-B) 24V DC input 4 (M12-C) 24V DC input 6 (M12-D) 24V DC inp
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 11 Default Data Map for Output Modules 1738-OB16E19M23, 1738-OB16E25DS, and 1738-OB16EM12 7 6 5 4 3 2 1 0 Fault LED state Fault 12-15 Fault 8-11 Fault 4-7 Fault 0-3 Produces 0 (scanner Rx) Not used Consumes 0 (scanner Tx) O7 06 05 04 03 02 01 0O Consumes 1 O15 O14 O13 O12 O11 O10 O9 O8 Where: O = Output 0 = off, 1 = on 1738-IB16DM12 7 6 5 4 3 2 1 0 Produces 0 (scanner Rx) I7 I6 I5 I4 I3 I2 I1 I0
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A Interpret LED Indicators 1738-OB16EM12 shown Fault LED status indicator FAULT 0-1 14-15 1738-OB16EM12/A MOD 24V DC Out NET 12-13 2-3 15 0 13 2 12 3 4 11 4-5 I/O status indicators 10-11 10 5 6 Network status indicator 14 1 I/O status indicators Module status indicator 6-7 8-9 9 8 7 44355 1738-OB16E19M23, 1738-OB16EM12, 1738-OB16E25DS, 1738-IB16DM12 Indicator Status Status Module status Fault status Description Off N
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 13 1738-OB16E19M23, 1738-OB16EM12, 1738-OB16E25DS, 1738-IB16DM12 Indicator Status Network status I/O status Status Description Off Device is not online: - Device has not completed dup_MAC-id test. - Device not powered – check module status indicator. Green Device is online and has connections in the established state. Flashing green Device is online but has no connections in the established state.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A Specifications ArmorPoint 24V DC Input Module, Series A - 1738-IB16DM12 Attribute Value Inputs per module 1 group of 16, nonisolated On-state voltage 10V DC minimum 24V DC nominal 28.8V DC maximum On-state current 2 mA minimum 4 mA @ 24V DC nominal 5 mA maximum Off-state voltage 5V DC Off-state current 1.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 15 ArmorPoint 24V DC Output Modules, Series A - 1738-OB16E19M23, 1738-OB16EM12, 1738-OB16E25DS Attribute Value Number of outputs 1 group of 16, nonisolated sourcing outputs On-state voltage drop 0.2V DC maximum On-state voltage 10V DC minimum 24.V DC nominal 28.8V DC maximum On-state current per channel 1.0 mA minimum 0.5 A maximum, electronically protected Off-state voltage 28.8V DC maximum External DC supply voltage 10...28.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A General Specifications Attribute Value Power dissipation 1738-OB16E19M23, 1738-OB16EM12, 1738-OB16E25DS – 3.0W @ 28.8V DC 1738-IB16DM12 – 2.7W @ 28.8V DC maximum Thermal dissipation 1738-OB16E19M23, 1738-OB16EM12, 1738-OB16E25DS – 10.3 BTU/hr @ 28.8V DC 1738-IB16DM12 – 9.2 BTU/hr @ 28.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 17 Environmental Specifications Attribute Value Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold), IEC 60068-2-2 (Test Bd, Operating Dry Heat), IEC 60068-2-14 (Test Nb, Operating Thermal Shock): -20…60 °C (-4…140 °F) Temperature, storage IEC 60068-2-1 (Test Ab, unpackaged nonoperating cold), IEC 60068-2-2 (Test Bb, unpackaged nonoperating dry heat): -40…85 °C (-40…185 °F) Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Dam
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A Certifications Certification (when Value product is marked)(1) CE European Union 2004/108/EC EMC Directive, compliant with: EN 61326; Meas./Control/Lab.
ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 19 Notes: Publication 1738-IN023B-EN-E - February 2010
