Kinetix 6000M Manual Brake Release Cable

Installation Instructions

Kinetix 6000M Manual Brake Release Cable

Catalog Number 2090-CBKS8-16AA03

About the Manual Brake Release Cable

The Kinetix® 6000M integrated drive-motor (IDM) unit is available with a spring-set holding

brake that automatically engages when 24V power is removed. During normal operation, the

brake is automatically controlled by the motion control system or manually controlled using

RSLogix 5000 commands. This cable lets you manually release or apply the brake on an IDM

unit during installation and maintenance, without having to connect and activate an IDM power

interface module (IPIM).

Topic Page

Important User Information 2

Before You Begin 3

Install the Cable 4

2090-CBKS8-16AA03 Cable Schematic and Connector Pinouts 5

Specifications 6

Additional Resources 6

Summary of content (8 pages)

PAGE 1
Installation Instructions Kinetix 6000M Manual Brake Release Cable Catalog Number 2090-CBKS8-16AA03 Topic Page Important User Information 2 Before You Begin 3 Install the Cable 4 2090-CBKS8-16AA03 Cable Schematic and Connector Pinouts 5 Specifications 6 Additional Resources 6 About the Manual Brake Release Cable The Kinetix® 6000M integrated drive-motor (IDM) unit is available with a spring-set holding brake that automatically engages when 24V power is removed.
PAGE 2
Kinetix 6000M Manual Brake Release Cable Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls, publication SGI-1.1, is available from your local Rockwell Automation sales office or online at http://www.rockwellautomation.
PAGE 3
Kinetix 6000M Manual Brake Release Cable 3 Before You Begin Remove all packing material from within and around the item. After unpacking, verify the catalog number against the purchase order, and visually inspect the cable and each connector for damage. If necessary, immediately notify the carrier of any shipping damage. Cables are stored and shipped in a coil, and will retain this shape unless you straighten the cable.
PAGE 4
Kinetix 6000M Manual Brake Release Cable Install the Cable Follow these steps when installing a 2090-CBKS8-16AA03 manual brake release cable. 1. If an IPIM module is installed, verify power to the IPIM module is removed before making any connections or disconnecting any components of the system. ATTENTION: Arcing or unexpected motion can occur if cables are connected or disconnected while power is applied to the IDM system.
PAGE 5
Kinetix 6000M Manual Brake Release Cable 5 8. Remove the 24V DC power to apply the brake and prevent shaft rotation. Kinetix 6000M Cable Routing Diagram 2090-CBKS8-16AA03 Manual Brake Release Cable Customer Supplied 24V DC @ 650 mA MDF-SB1xxx Offline IDM Unit The colored rings on the hybrid cable connector and the mating cable must match: red-to-red or green-to-green.
PAGE 6
Kinetix 6000M Manual Brake Release Cable Specifications Additional specifications for each cable are available in the Kinetix Motion Accessories Technical Data, publication GMC-TD004. Attribute 2090-CBKS8-16AA03 Wire size 18 AWG Diameter (1) 8.13 mm (0.320 in.) Bend radius Installation areas 97.6 mm (3.84 in.) (2) (1) Cable diameter tolerance is ± 0.13 mm (0.005 in.). (2) The installation areas are 300 ± 25 (12 in. ± 1.0) in length at both ends of the cable.
PAGE 7
Kinetix 6000M Manual Brake Release Cable 7 Notes: Publication 2090-IN037B-EN-P - March 2012
PAGE 8
Rockwell Automation Support Rockwell Automation provides technical information on the Web to assist you in using its products. At http://www.rockwellautomation.com/support, you can find technical manuals, technical and application notes, sample code and links to software service packs, and a MySupport feature that you can customize to make the best use of these tools. You can also visit our Knowledgebase at http://www.rockwellautomation.
