NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 INSTRUCTION MANUAL SRC-800 Video Cassette Recorder Please read this manual and accompanying “IMPORTANT SAFETY INSTRUCTIONS” sheet carefully before connecting your VCR and operating it for the first time. Be sure to read carefully and follow all the PRECAUTIONS on page 2. Keep the manual in a safe place for future reference.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 PRECAUTIONS THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THIS UNIT. DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 FEATURES CONTENTS • High-speed Fast Forward/Rewind • 8-hour mode recording audio playback • On-screen mode setting • Integrated time date generator • Day/Time search function • Forward field advance function • 30-day memory backup • Security lock • Head-cleaning function PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 ACCESSORY . . . . . . . . . . . . . . .
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 LOCATIONS OF CONTROLS AND INDICATORS Front Panel 1 2 3 4 5 6 7 89F STANDBY/ON TAPE END PAUSE/ SEARCH REW PLAY FF MENU RESET STOP REC EJECT ON SCREEN ON OFF P O MENU TRACKING V.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 LOCATIONS OF CONTROLS AND INDICATORS 5 Operation Indicators Digital Display 1 2 T/D P • They display the actual operation mode. 34 Operation Mode Record (REC) M Record pause (REC PAUSE) Playback (PLAY) Still image (STILL) 6 Fast forward (FF) 5 Rewind (REW) 1 Mode display Cue (CUE) • Recording/playback Review (REVIEW) speed mode Field shift forward (FIELD SHIFT +) • Day/Time search mode T/D 6 Cassette indicator Comes on when a cassette is loaded.
NU4Q/U (SRC-800 GB) Fri. Aug.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 CONNECTIONS Connect the video camera and monitor TV as shown in the figure below. NOTE: Before making the connections, make sure all the devices are disconnected from the power outlet.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 TYPES OF ON-SCREEN DISPLAYS AND DISPLAY SEQUENCE NOTES: • When a menu is displayed, recording will not be possible. • Press the PAUSE/SEARCH or MENU button, the setting procedure is now completed. • During recording or playback the menus cannot be displayed. • To reset the settings of a menu to their original values, select the desired menu then press the MENU RESET button. The (USED TIME) menu data cannot be reset.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 SETTING THE LANGUAGE AND CLOCK 6 Press the l (or j) button to set the time the daylight Language Setting saving time adjustment is made. English or French can be selected by the user. 7 Press the ] button. 8 Following the same procedure as above (steps 4 to 1 Turn the power on to all devices used. 2 Press the MENU button to display the (SET UP 1) 6), set when the time is changed back from daylight saving time to standard time. menu. 9 Press the ] button.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 CHANGING THE ON-SCREEN DISPLAY Selecting the On-screen Display Changing the Date/Time Display Position You can select to display or not the date and time. 1 Turn the power on to all devices used. 2 Set the ON SCREEN switch to the “ON” position. 1 Turn the power on to all devices used. 2 Press the MENU button until the (SET UP 2) menu is ° The date and time are displayed. displayed.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 VIDEO CASSETTE TAPES Use only video cassette tapes bearing the w logo. This VCR was primarily designed for use with T-160 cassette tapes, it is recommended to use T-160 VHS video cassette tapes for optimal performance. Unloading Handling Cassette Tapes NOTES: 1 In STOP mode, press the EJECT button. ° The cassette is automatically ejected.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 NORMAL RECORDING [Recording Speed] Normal Recording 1 Turn the power on to all devices used. 2 Load a cassette tape with erasure-prevention tab.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 NORMAL RECORDING Setting the Mode at the End of the Tape TAPE END Indicator Setting In the (SET UP 2) menu, you can set the mode of the VCR mode when the tape reaches the end during recording. 1 Press the MENU button until the (SET UP 2) menu is displayed.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 SERIES RECORDING Using 2 VCRs or more, the series recording function lets you switch recording from one unit to the next (only with VCRs of the same model as this one). The SERIES OUT signal will be presence either at the point when the counter reading is 7:57:00 or when VCR No. 1 reaches the end of the tape, whichever is first. The signal will stop 70 seconds after the tape end point of VCR No. 1. Series Recording Setup When this signal is received by VCR No.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 SERIES RECORDING Continous Loop Recording Setup NOTES: • The “TAPE END MODE” in (SET UP 2) menu should It is possible to configure at least two this VCR for continous loop recording. be set to "REW" for both units without fail. • The TAPE END indicator will continue to bink when the Under loop recording when the recording finishes on the first unit, the new recording will start on the second unit.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 PLAYBACK Normal Playback Picture Search 1 Turn on the power to the VCR and TV monitor. 2 Load the video cassette tape. 3 Press the PLAY button. 1 Press the FF (or REW) button, during normal playback. The image can be seen while the tape is ° advanced (or rewound) at high speed. ° Playback starts. necessary, adjust the tracking to eliminate the ° Ifnoise from the picture. 2 To return to normal playback, press the PLAY button.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 DAY/TIME SEARCH Day/Time Search To search for a recording when the date and time the recording was performed on are known. 1 Press the PAUSE/SEARCH button during stop mode. SEARCH 01 00” will be displayed on ° “T/D screen. Day/Time Search Example 0H25M39S T/D SEARCH 01 15 Time Day 2 Press the l (or j) button to set the desired day, then press the « button. 3 Press the l (or j) button to set the desired hour. 4 Press the FF (or REW) button.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 SETTING THE SECURITY LOCK The security lock function is designed to prevent accidental stopping of recording if the STOP button is pressed inadvertenly. NOTES: 1 While holding the TRACKING/V.STILL + button, • The security lock cannot be engaged while a menu is • While the security lock is engaged all commands, except the one to cancel the security lock, are disabled. press the l button. ° displayed. “ö” is displayed on the digital display.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 SETTING THE CASSETTE EJECT MODE EJECT terminal connection Cassette Eject Setup When using 2 VCRs or more, the cassette tape of all the VCRs or some of the VCRs can be ejected, if the EJECT terminals on the VCRs are connected as indicated. VCR No. 1 COM EJECT OUT IN VCR No. 2 COM EJECT OUT IN 1 Press the MENU button until the (SET UP 2) menu is displayed.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 CHECKING USAGE DURATION, POWER FAILURE AND FAILURE DUE TO CONDENSATION 1 Press the MENU button, until the (POWER Example FAILURE), (DEW) and (USED TIME) menu is displayed. 002 FAILURE 12-10 07:15 RECOVERY12-10 07:30 (POWER FAILURE). . . The number of power failures, and the date and time of the most recent power failure and recovery are displayed. 001 FAILURE 12-10 11:00 RECOVERY12-10 12:00 VIDEO 00003H POWER 00007H (DEW) . . .
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 MAINTENANCE Daily Inspection Periodic Inspection The following daily inspections are recommended in order to assure long-term and trouble-free operation of the unit. Periodic inspection and maintenance should be referred to your dealer. The daily inspections are particularly important. If there is noise in the playback picture, and it cannot be corrected using the tracking control, it may indicated that the video heads need cleaning.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 TROUBLESHOOTING GUIDE If the unit does not operate normally when you follow the instructions indicated in the manual, please refer to the table below.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 SPECIFICATIONS General Specifications Video heads system Audio recording Tape speed Specified video cassette tape Recording/playback time Fast forward/rewind time Television system Dual-azimuth 4-head rotating helical scanning system: Dual azimuth 2-head for record and standard playback Dual azimuth 4-head for cue, review and still mode In 8-hour modes 11.
NU4Q/U (SRC-800 GB) Fri. Aug., 06/1999 SANYO INDUSTRIAL VIDEO VCR LIMITED WARRANTY OBLIGATIONS In order to obtain warranty service, the product must be delivered to and picked up from an Authorized Sanyo Service Center at the user’s expense, unless specifically stated otherwise in this warranty.
