ODYSSEY – STM32MP157C Reference Guide Overview Description The ODYSSEY – STM32MP157C is a single board computer that is based on STM32MP157C, a dual-core Arm® Cortex®-A7 processor operating at 650Mhz. The processor also integrates an Arm® Cortex®-M4 coprocessor, which makes it suitable for real-time tasks. The ODYSSEY – STM32MP157C is created in a form of SoM (System-On-Module) with a carrier board. The SoM consists of an MPU, PMIC, RAM and the carrier board is in Raspberry Pi form factor.
ODYSSEY – STM32MP157C Reference Guide Specifications SoM – STM32MP157C 38mm • MPU: STM32MP157C 32-bit Dual-Core Arm® Cortex®-A7 32-bit Arm Cortex®-M4 with FPU/MPU • PMU: ST PMIC STPMIC1A 38mm • RAM: 512MB DDR3 RAM • Flash: 4GB eMMC • Peripherals: 3 x Board-to-Board 70-Pin Connectors • Dimensions: 38mm x 38mm Carrier Board • Peripherals 85mm 2 x USB Host 1 x Gigabit Ethernet 1 x 3.
ODYSSEY – STM32MP157C Reference Guide Hardware Overview Carrier Board Pinout Diagram ODYSSEY - STM32MP157C’s 40-pins are fully compatible with Raspberry Pi's 40-pins including GPIO, I2C, UART, SPI, I2S and PWM pins. SoM Components Details www.seeed.
ODYSSEY – STM32MP157C Reference Guide 1.STM32MP157C: Development Board Main Control Chip (Dual architecture processor: Arm® Cortex®-A7 and Cortex®-M4 ) 2.MT41K256M16TW-107:P: 512MB 16-bit RAM Memory Chip 3.STPMIC1APQR: Power Management Chip 4.EMMC04G-M627: 4GB eMMC Memory 5.LED: When the power supply is successful, the PWR LED will turn on. When the system is running normally, the USER LED will keep flashing. 6, 7, 8: 70-PIN connectors Carrier Board Components Details www.seeed.
ODYSSEY – STM32MP157C Reference Guide 1.Seeed SoM-STM32MP157C Installation Area: If the user wants to remove the core board, slowly tilt the core board up and then remove. Never remove by hand. 2.DC Power Input Port: 12V~24V/2A (12V/2A power input is recommended). 3.ETH Interface: Network cable interface can be connected to Gigabit Level Network. 4.USB Host: Two USB Host ports. 5.USB Device: USB 2.0 Type C. If Type C is used as board power input, a 5V/3A power adapter should be used. 6.
ODYSSEY – STM32MP157C Reference Guide FCC Regulatory Compliance Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
ODYSSEY – STM32MP157C Reference Guide If you want to learn about setting up the software and other details, please visit the product wiki at http://wiki.seeedstudio.com/ODYSSEY-STM32MP157C/ If you still have any further questions, please visit forum.seeedstudio.com © 2008-2020 Seeed Technology Co.,Ltd. All rights reserved. www.seeed.
