Reference Guide

ODYSSEY – STM32MP157C

Reference Guide

Specifications

• MPU: STM32MP157C

32-bit Dual-Core Arm® Cortex®-A7

32-bit Arm Cortex®-M4 with FPU/MPU

• PMU: ST PMIC STPMIC1A

• RAM: 512MB DDR3 RAM

• Flash: 4GB eMMC

• Peripherals: 3 x Board-to-Board 70-Pin Connectors

• Dimensions: 38mm x 38mm

SoM – STM32MP157C

Carrier Board

• Peripherals

2 x USB Host

1 x Gigabit Ethernet

1 x 3.5mm Audio

1 x MIPI DSI for Screen

1 x DVP for Camera

2 x Grove (GPIO & I2C)

1 x SD Card Slot (on the back)

• WiFi/BLE

WiFi 802.11 b/g/n 2.4GHz

Bluetooth 4.1 with BLE

• On-Board LED: 1 x Reset, 3 x User, 1 x Power

• Power

1 x DC Jack 12V~24V/2A (12V/2A power input is recommended)

1 x USB Type-C

• Button

1 x Reset

1 x User

1 x Switch

• Dimensions: 56mm x 85mm

• Operating Temperature: 0 ~ 75°C

38mm

85mm

38mm

56mm
