Thank you for purchasing this SHARP product. For the best performance, read this manual carefully. It will guide you in operating your SHARP product. PORTABLE MINIDISC RECORDER MODEL MD-MT888H OPERATION MANUAL If you require any advice or assistance regarding your Sharp product, please visit our web-site www.sharp.co.uk/support. Customers without Internet access may telephone 08705 274277 during office hours (or (01) 676 0648 if telephoning from Ireland). 0101 MT888H_UK_F 1 01.8.
MD-MT888H -Accessories- Important Introduction Accessories Remote control x 1 Earphones x 1 AC adaptor (RADPA8046AWZZ) x1 Battery carrying case x 1 Rechargeable nickel-metal hydride battery (AD-N55BT) x1 Battery charger x 1 Connection cable (for analogue recording) x 1 Connection cable (for digital recording) x 1 Carrying bag x 1 Battery case x 1 Notes: z Parts and equipment mentioned in this operation manual other than those detailed above are not included.
Contents „ Advanced Features Page Special Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Names of Controls and Indicators . . . . . . . . . . . . 7 - 9 Page Titling a MiniDisc . . . . . . . . . . . . . . . . . . . . . . . . 40 - 42 Editing a Recorded MiniDisc . . . . . . . . . . . . . . 43 - 50 Hold Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Changing Default Settings . . .
MD-MT888H Special Notes -Special Notes- Important Introduction „ Warnings z The supplied AC adaptor contains no user serviceable parts. Never remove covers unless qualified to do so. It contains dangerous voltages, always remove mains plug from the main outlet socket before any service operation or when not in use for a long period. z The AC adaptor supplied with the MD-MT888H must not be used with other equipment.
MD-MT888H z Recording and playback of any material may require consent, which SHARP is unable to give. Please refer particularly to the provisions of the Copyright Act 1956, the Dramatic and Musical Performers Protection Act 1958, the Performers Protection Acts 1963 and 1972 and to any subsequent statutory enactments and orders. z This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. z US and foreign patents licensed from Dolby Laboratories.
MD-MT888H Precautions z Do not wear your earphones when you are crossing streets or near traffic. z Do not use your earphones whilst driving a motor vehicle, it may create a traffic hazard and may be illegal. Remember to obey all of the safety rules in your area. -Precautions- Important Introduction „ Important z Do not play the unit at a high volume. Hearing experts advise against extended listening at high volume levels. z If you experience ringing in your ears, reduce the volume or discontinue use.
Names of Controls and Indicators 2 1 MD-MT888H „ Main unit 3 Reference page 7 6 12 8 9 11 10 14 15 16 17 18 21 22 13 19 20 1. Synchronised Recording Button . . . . . . . . . . . (28) 2. Mode Button . . . . . . . . . . . . . . . . . . . . . . (19, 26, 29) 3. Volume Buttons . . . . . . . . . . . . . . . . . . . . . . . . . (24) 4. Record Button . . . . . . . . . . . . . . . . . . . . . . . (19, 31) 5. Play/Pause/Stop/Power Off/Hold/Fast Forward/ Fast Reverse Button . . . . .
MD-MT888H Names of Controls and Indicators (continued) „ Remote control unit 3 2 4 5 Important Introduction 1 -Names of Controls and Indicators- Reference page 6 7 8 9 10 11 15 16 17 12 13 14 18 19 20 1. Earphones Socket . . . . . . . . . . . . . . . . . . . . . . (22) 2. Record Button . . . . . . . . . . . . . . . . . . . . . . . (19, 31) 3. Volume Buttons . . . . . . . . . . . . . . . . . . . . . . . . . (24) 4. Mode/Display Button. . . . . . . . . . . . . . . (19, 26, 38) 5.
Menu display Various operations are performed by moving the M button on the remote control all around or pressing it. When the unit enters the menu mode, the initial letter of each menu will be displayed in the first line and the contents of the selected menu in the second line. If you move the M button toward ... Playback, pause, selecting a character If you move the M button toward ...
MD-MT888H Using with the Rechargeable Battery „ Charging Preparation -Using with the Rechargeable Battery- When the rechargeable battery is used for the first time or when you want to use it after a long period of disuse, be sure to charge it fully. 1 2 3 Insert the rechargeable battery. Connect the AC adaptor. Place the unit on the battery charger. z When the portable MD is turned on or operating, the battery will not be charged. z No operation can be performed whilst charging.
„ Display of remaining amount of battery „ Charging time When the unit is set on the charger, the remaining amount of battery is displayed. Charging is completed in about 3 hours, and the display of remaining amount of battery will go out. 90 % of charging is completed. If you leave it for another 2 hours, the battery will be fully charged. z Charge the battery within the range of 5°C - 35°C (41°F - 95°F). z The unit can be left in the charging state after it is completed. Display Conditions Charging.
MD-MT888H Using with the AC Adaptor 1 2 Preparation -Using with the AC Adaptor- 3 Take out the lead from the charger. Connect the lead to the main unit (at DC IN 2 V socket). Connect the AC adaptor. Caution: z If the AC adaptor is not used for a long period of time, be sure to remove the plug from the socket for safety. z Insert each plug fully. Note: When the power failure occurs whilst playing back music using the AC adaptor, unplug the unit.
Using with the Alkaline Battery 1 2 3 Open the battery case cover. Insert an alkaline battery into the battery case. Attach the battery case to the unit. Caution: Do not put a rechargeable battery (nickel-cadmium battery, etc.) in the battery case. Inserting a MiniDisc 1 2 3 Slide the OPEN lever to release the compartment door. Insert a MiniDisc as shown. Close the compartment door. Notes: z Do not place the MiniDisc under the holder.
MD-MT888H Connections -Connections- Preparation You can record your favourite CDs or tapes to MD. 14 01/8/30 2.
01/8/30 2.
MD-MT888H Long Time Recording and Group Recording Basic Operation -Long Time Recording and Group Recording- „ Long time recording Since this MD portable recorder adopts the 4 times long recording mode, you can record many tracks on one MD (supporting MDLP). Up to 320 minutes of recording is possible on one MD (of 80 minutes). „ Group recording You can record tracks by the group of artists or albums, etc. That MD can be played by selecting the group.
Group Playback Using a group-recorded MD, you can play back tracks by the desired group (albums, artists, etc.). „ Playback of group-recorded MD MD-MT888H Setting the group mode Inserting a group-recorded MD automatically sets the unit to the group mode. (The first group is displayed.) When the group mode is selected ("GROUP" lights up) Tracks are played by the group, starting with the first track of the group. You can select a group to play back.
Recording -Recording- Basic Operation MD-MT888H 18 01/8/30 3.
MD-MT888H 2 Hold down the REC button for 2 seconds or more. 6 Here you can search for the track to record. 7 You can perform the same operation by simply pressing the REC button on the main unit. 3 To perform group recording, hold down the GROUP button for 1 second or more so that "GROUP" is lit. z The unit is ready to record a new group. (To select a group, refer to page 21.) z When group recording is not performed, hold down the GROUP button for 1 second or more so that "GROUP" goes out.
MD-MT888H Recording (continued) To interrupt recording „ Recording level Analogue recording Adjust the recording level so that the maximum sound volume from the source makes the reading swing somewhere between -4 dB and 0 dB. You can check the level on the LCD of the main unit. To stop recording -Recording- Basic Operation Move the M button toward . z Recording starts by moving the M button toward again. z You can perform the same operation by pressing the button on the main unit.
MD-MT888H more to display "GROUP". 3 Press the M button. The unit enters the menu select mode. 4 Move the M button toward or to select "G(GrSELECT)" and press it. 5 Move the M button toward or to select the group you want to add tracks to and press it. NEWGr To create a new group. Gr01, Gr02, Gr03... To add tracks to an existing group. (If the group name has been recorded, the name will be displayed instead of "Gr01".) NonGr To record tracks as non-group. 6 Start recording.
Playback -Playback- Basic Operation MD-MT888H 22 01/8/30 3.
z You can perform the same operation by pressing the button on the main unit. „ 3-colour indicators Plug the remote control and earphones into the unit. 2 Insert a MiniDisc (page 13). Inserting a group-recorded MD automatically sets the unit to the group mode. 3 Start playback by moving the M button toward . Notes: z If power failure occurs whilst playing a disc using the AC adaptor, disconnect it from the wall socket. Otherwise, playback may start automatically when electricity resumes.
MD-MT888H Playback (continued) „ Volume control Press the VOLUME+ button to increase the volume and the VOLUME- button to decrease the volume. „ To search a desired group 1 „ Bass control 3 -Playback- Basic Operation 1 2 Press the GROUP button so that the "GROUP" flashes. Press the M button. Move the M button toward or to select "B(BASS)" and press it. Move the M button toward or the bass strength and press it. O(OFF) 1(BASS1) 2(BASS2) 3(BASS3) to select Cancelled. Emphasised slightly.
Advanced Playback MD-MT888H „ To locate the beginning of a track For audible fast forward: During playback, keep moving the M button toward . For audible fast reverse: During playback, keep moving the M button toward . once. To locate the next track: In the stop mode, move the M button toward once. To locate the previous track: In the stop mode, move the M button toward once. z To skip a number of tracks at one time, move the M button toward or repeatedly until the desired track number is shown.
MD-MT888H Advanced Playback (continued) „ Random play or repeat play -Advanced Playback- Useful Features During playback, press the MODE button repeatedly to select the playback mode. z Repeat play lasts until you stop the unit. z In random play the unit will select and play tracks automatically. (You cannot select the order of the tracks.) After all of the tracks have been played once in random order, the unit will stop automatically.
MD-MT888H „ To play at double speed A MiniDisc recorded in the monaural mode can be played back at double speed audibly. (Monaural recording, page 29) 1 During playback, press the M button. You can listen to the beginning of each track for 5 seconds in the recorded order. Whilst the playback is stopped or paused, Keep moving the M button toward for 2 seconds or more. z Intro play cannot be performed whilst the random, random repeat, or one-track repeat mode is selected.
MD-MT888H Advanced Recording „ Playback sound-actuated recording 5 Recording automatically starts or pauses by detecting sound from the stereo system (Synchronised recording). Select the starting point for your recording and press the PAUSE button. 6 -Advanced Recording- Useful Features 7 1 Hold down the REC button for 2 seconds or more. You can perform the same operation by simply pressing the REC button on the main unit.
MD-MT888H „ Long-play recording Monaural recording In monaural, you can record twice as long as the stereo recording. A track recorded in monaural can be played back in double speed, see page 27. 1 When a recording is paused, press the MODE button repeatedly to select the recording mode. Each time the button is pressed, the display will change as follows. 2 -Advanced Recording- 2 times and 4 times long recording Double or quadruple time of stereo recording is possible.
-Advanced Recording- Useful Features MD-MT888H Advanced Recording (continued) Notes: z Tracks can be recorded in stereo recording mode, 2 times long recording mode, and 4 times long recording mode on one MiniDisc. z In monaural recording, the sound on the right and left channels is mixed even if the input source is in stereo. Although you can hear the stereo sound from the earphones, the recorded sound is monaural.
MD-MT888H „ To create your own track numbers „ Recording tracks as a single track You can create your own track numbers at any point. You can record several pieces of music as a single track by disabling the auto marker function. Whilst recording, press the REC button at the point where you want to create track numbers. 1 The track number will be increased by one. Whilst the recording or recording is paused, press the M button.
MD-MT888H Advanced Recording (continued) „ About track numbers -Advanced Recording- Useful Features 1. Track numbers are created automatically during recording via the analogue connection when a silence of 1 second or more is detected (Auto marker function). A series of tracks can be recorded as one by disabling the auto marker function, see page 31. z Track numbers may not be created in proper places, depending on the source to be recorded from, such as signals with noise.
MD-MT888H This portable MD incorporates a sampling rate converter meaning it can record from digital radios or DAT tape recorders. „ Note for digital recording You cannot copy a MiniDisc that you recorded from digital inputs to another MiniDisc or DAT. It is prevented by the SCMS (Serial Copy Management System). Recording from analogue inputs is not affected.
MD-MT888H Recording from a Microphone Useful Features -Recording from a Microphone- „ To record from a microphone 1 Connect a stereo microphone to the MIC IN socket. 2 3 Insert a recordable MiniDisc (page 13). Hold down the REC button for 2 seconds or more. You can perform the same operation by simply pressing the REC button on the main unit. 4 To perform group recording, hold down the GROUP button for 1 second or more so that "GROUP" is lit.
MD-MT888H or to ad- The same operation can be performed by pressing the or button on the main unit. To interrupt recording Move the M button toward . z Recording starts by moving the M button toward again. z You can perform the same operation by pressing the button on the main unit. z The track number will be increased by one each time the recording is interrupted. To stop recording Move the M button toward . You can perform the same operation by pressing the button on the main unit.
MD-MT888H Recording from a Microphone (continued) „ Sound-actuated recording (Mic Synchronised recording) 7 Useful Features -Recording from a Microphone- The unit automatically pauses when the microphone does not pick up any sound for 3 seconds or more. (Pause function does not work for approximately 10 seconds after a recording starts.) When the microphone picks up sound again, recording starts automatically. 1 Hold down the REC button for 2 seconds or more.
MD-MT888H „ Track intervals When recording from the microphone, track numbers will be created automatically at regular intervals (default setting: approximately every 5 minutes). During a mic synchro recording, the unit pauses when a silence lasts for 3 seconds or more, and creates a track number. z If you press the CLEAR button during the operation, the previous display appears. z To cancel the operation, move the M button toward . Example: Set to "5 minutes".
MD-MT888H Checking Displays „ To check the remaining recording time and the total playing time Whilst in the stop mode, hold down the DISP button for 1 second or more. „ To display the playing time of an individual track 1 Whilst in the stop mode, move the M button toward or to select a track number or name. 2 Hold down the DISP button for 1 second or more. -Checking Displays- Useful Features Each time the button is pressed, the display will change as follows.
MD-MT888H The remaining amount of battery level is shown by the battery indicator ( ) during operation. Each time the button is pressed, the display will change as follows. z When the battery is completely discharged, the battery indicator will flash. Recharge the battery or replace the alkaline battery with a new one. z When the battery has run out completely, "LoBATT" will appear. Then, the power will be disconnected automatically.
MD-MT888H Titling a MiniDisc z Load a MiniDisc to be named. A playback only or recording prevented MiniDisc cannot be edited. z The group-recorded MD may not be edited properly with other equipment. 4 Move the M button toward to select the type of characters. -Titling a MiniDisc- Advanced Features The group-recorded MD contains the menus that cannot be edited if the group mode has been cancelled. Select the group mode before editing.
MD-MT888H „ Creating a group name „ Creating a track name Select the group mode. 1 Whilst in the stop mode, press the M button. Move the M button toward or to select "N(NAME)" and press it. 3 Move the M button toward or to select "G(GROUP)" and press it. Move the M button toward or to select the group you want to name and then press it. 4 The unit will enter the character input mode. 5 Enter the characters (page 40, steps 4 - 8). The unit enters the menu select mode.
MD-MT888H Titling a MiniDisc (continued) „ To erase a character „ Characters (symbols) 1 Set the unit to character input mode. Disc name : page 40, steps 1 - 3 Group name : page 41, steps 1 - 4 Track name : page 41, steps 1 - 3 the cursor to the character you want to erase, and then press the REC button. 3 Hold down the M button for 1 second or more. -Titling a MiniDisc- Advanced Features 2 Press the VOLUME+ or VOLUME- button to move „ To add characters A B C D E F G H I S T U V W X Y Z .
Editing a Recorded MiniDisc MD-MT888H „ To erase one track at a time „ To erase all of the tracks at once You can erase one track at a time. You can erase all tracks at once. 1 1 Move the M button toward or to select "E(EDIT)" and press it. 4 5 Move the M button toward or to select "E(EDIT)" and press it. 3 Move the M button toward or "A(ALL ERASE)" and press it. Press the M button. Move the M button toward "E(ERASE)" and press it. Press the M button.
Advanced Features -Editing a Recorded MiniDisc- MD-MT888H Editing a Recorded MiniDisc (continued) „ To divide a track „ To move a track You can divide a track into 2 tracks. You can move a track to the desired position. 1 1 2 Play back the track to be divided, and move the M button toward at the point where you want to divide the track to pause it. Press the M button. The unit enters the menu select mode. 3 Move the M button toward or to select "E(EDIT)" and press it.
Two adjacent tracks can be combined. 1 2 Play back the second of the two tracks to be combined and move the M button toward to pause it. Press the M button. The unit enters the menu select mode. 3 Move the M button toward or to select "E(EDIT)" and press it. 4 Move the M button toward "C(COMBINE)" and press it. Press the M button. 5 The two tracks will be combined, and the unit will be paused at the beginning of the combined track.
MD-MT888H Editing a Recorded MiniDisc (continued) „ Moving a track to another group „ Moving a group to the top On a group-recorded MD, you can move a track to a different group. (Group change) On a group-recorded MD, group-recorded tracks can be moved to the beginning of the MiniDisc. (Group top move) Advanced Features -Editing a Recorded MiniDisc- 1 2 Play back the track to be moved, and move the M button toward to pause it. Press the M button. The unit enters the menu select mode.
MD-MT888H 1 2 Whilst in the stop mode, select the group you want to erase (page 24). Press the M button. z Complete the operation within 25 seconds whilst selecting the menus. z If you press the CLEAR button during the operation, the previous display appears. z To cancel the operation, move the M button toward . The unit enters the menu select mode. 3 Move the M button toward or to select "G(GROUP)" and press it. 4 Move the M button toward or "E(Gr&TrERASE)" and press it. Press the M button.
MD-MT888H Editing a Recorded MiniDisc (continued) „ Stamping titles from another MiniDisc Before stamping Advanced Features -Editing a Recorded MiniDisc- When there are 2 MiniDiscs on which the same tracks are recorded, you can transfer the character information (disc, group, and track names) of the master MiniDisc to another MiniDisc (for stamping) simultaneously. Master MiniDisc operation 1 Do not mistake the master MiniDisc for the target one. 2 2.
MD-MT888H Operation of the MiniDisc for stamping „ Creating a group before recording 7 You can create a group in advance and record tracks in it. Load a MiniDisc for stamping. 1 Whilst in the stop mode, press the M button. 3 Move the M button toward or "R(GrRESERVE)" and press it. Press the M button. The unit will finish recording the character information and enter the stop mode. to select The unit will enter the character input mode.
MD-MT888H Editing a Recorded MiniDisc (continued) „ Moving non-group tracks to after group-recorded tracks Advanced Features -Editing a Recorded MiniDisc- If non-group tracks are found in the middle of a grouprecorded MD, they can be moved to after group-recorded tracks. (Group arrange) 1 Whilst in the stop mode, press the M button. The unit enters the menu select mode. 2 Move the M button toward or to select "G(GROUP)" and press it. 3 Move the M button toward or "A(GrARRANGE)" and press it.
Hold Function MD-MT888H If the battery is inserted or the AC adaptor is connected, you can set this function even when the power is turned off. To cancel the hold mode Move the HOLD switch away from the safety position (the opposite direction of the arrow). To cancel the hold mode Press and hold down the (HOLD) button for 2 seconds or more whilst the unit is in the hold mode. "oFF" will be shown.
MD-MT888H Changing Default Settings 1 2 -Changing Default Settings- Advanced Features 3 4 5 Insert a MiniDisc. Menu Item Whilst in the stop mode, press the M button. B(BEEP) Y(YES) * The unit enters the menu select mode. Beep sound N(NO) Move the M button toward or to select "S(SETUP)" and press it. Move the M button toward or to select a menu and press it. Move the M button toward or to select an item and press it. z Complete the operation within 25 seconds whilst selecting the menus.
„ 3-colour indicators lighting and backlight on the remote control „ Auto play "NORM" You can eliminate the confirmation sound that beeps when you press a button. You can make the unit not play automatically when you insert a playback-only MiniDisc or an accidental erasure protected MiniDisc. „ Auto power save When the unit is used in a place exposed to much vibration, sound skipping can be decreased by cancelling the auto power save function. (Battery will drain faster.
MD-MT888H Listening through Another System Advanced Features -Listening through Another System- „ Listening through a stereo system Notes: z It is recommended that the volume level of the MiniDisc unit be set to maximum when listening through a stereo system. z When recording with stereo system, eliminate the confirmation sound (page 52). Otherwise, it will also be recorded. z The recording will be made in the analogue mode. z Character information will not be recorded.
Other Features and Caution „ Rechargeable battery When you stop playback and replay the MiniDisc without removing it, playback starts from the point you stopped it. z A rechargeable nickel-metal hydride battery is the only kind that can be used. Even if the battery is not used, you should charge it at least once every three months because of the special quality of this battery. z The rechargeable battery can be charged approximately 300 times.
MD-MT888H Troubleshooting Many potential "problems" can be resolved by the owner without calling a service technician. If something seems to be wrong with this product, check the following before calling your authorised SHARP dealer or service centre. The unit does not turn on.
MD-MT888H z Has the recording level been properly adjusted? z Is the unit connected properly to the other equipment? z Is the AC adaptor unplugged or did a power failure occur whilst recording or editing? z Is the unit in the hold mode? z Is an optical signal being output from the stereo system? Read the operation manual for the stereo system. The battery cannot be charged.
MD-MT888H MiniDisc System Limitations References -MiniDisc System Limitations- The unit may have the following symptoms whilst recording or editing. The unit is not out of order. SYMPTOM LIMITATIONS "D-FULL" or "T-FULL" appears even though the MiniDisc still has recording time left. More than the limited number of tracks (255) cannot be recorded regardless of the recording time.
Error Messages z Nothing is recorded. ERROR MESSAGES Can'tSTAMP (Replace the disc with a recorded disc.) busy z A track is being moved. Can'tC z You tried to record from a copy prohibited MiniDisc. z You tried to record signals other than music (such as data). (Record using the analogue cable.) Can'tE z A track cannot be edited. z You tried to record or edit the MD whilst operating the OPEN lever. z Stamp function does not work. (Check the number of tracks.
MD-MT888H Error Messages (continued) ERROR MESSAGES G-FULL MEANING z The total number of groups exceeds 99. ERROR MESSAGES NoTRACK z There is no track to be played. PLAYmd z You tried to record on a playback-only disc. References (Erase unnecessary groups.) -Error Messages- MEANING HOLD z The unit is in the hold mode. POWER ? z The battery charger is defective. LoBATT z The rechargeable or alkaline battery has run down.
Maintenance z The track has been protected from being erased. (Edit the track with the device on which it was recorded.) ?DISC „ Cleaning When the unit becomes dirty Clean it with a soft cloth. When the unit is excessively dirty, use a soft cloth dampened in water (external surfaces only). z A disc which contains data other than music was played. (A disc which contains nonmusic data cannot be played.) ?GrForm z The group recording or the GROUP RESERVE function cannot be performed.
MD-MT888H Specifications As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units.
MD-MT888H Battery life: 4 times long Continuous play: Approx. 13.5 hours Continuous recording: Approx. 11 hours Continuous play: Approx. 16 hours Continuous recording: Approx. 14 hours Continuous play: Approx. 18.5 hours When using one, commercially available, high capacity, "AA" size (LR6), alkaline battery (The rechargeable battery is in the unit, discharged.) Continuous recording: Approx. 9 hours Continuous play: Approx. 20 hours Continuous recording: Approx. 14 hours Continuous play: Approx.
TERMS OF GUARANTEE Subject to the terms listed below, Sharp Electronics (U.K.) Ltd. (hereinafter called “the Company”) guarantee to provide for the repair of, or at its option replace this Sharp Equipment, or any component thereof, (other than batteries), which is faulty or below standard, as a result of inferior workmanship or materials. The conditions of this guarantee are: 1.
