-12
Projector (Rear View)
Using the Kensington Lock
• This projector has a Kensington Security Standard connector for use with a Kensington MicroSaver Security
System. Refer to the information that came with the system for instructions on how to use it to secure the
projector.
Part Names
Numbers in refer to the main pages in this operation manual where the topic is explained.
23
60
Rear adjustment
foot
(on the bottom of
the projector)
55
AC socket
Exhaust vent
55
RGB OUTPUT
terminal
Terminal for
connecting a monitor.
51
INPUT 1 terminal
Terminal for
computer RGB and
component signals.
54
RS-232C terminal
Terminal for controlling
the projector using a
computer.
Kensington
Security Standard
connector
51
AUDIO INPUT
terminal
Shared audio input
terminal for INPUT
1, 2 and 3.
52
INPUT 2 terminal
Terminal for
connecting video
equipment with an
S-video terminal.
52
INPUT 3 terminal
Terminal for
connecting video
equipment.
