Instruction Manual
Charging Battery
Step 1 - Pre-Flight Checklist.
1. Read all warnings and instructions.
2. Install remote batteries, page 4.
3. Charge batteries, page 4.
4. Make sure that the drone and remote are powered o.
Step 2 - Choosing a location.
• Drone is designed to be flown indoors and outdoors.
• Always make sure you have enough space to fly drone.
• Always follow warnings, page 2.
Step 3 - Pre-Flight
• Make sure your remote is o.
• Push the power button on top of the drone and hold on 1-2s until LED lights on.
• Place drone on a flat even surface. For ease of control, the blue lights should be toward you.
• Turn on the Remote controller.Push the left stick up and then down.
• The drone’s lights will flicker during the pairing process and then remain on once it has paired.
Press the Auto Orientation Button to turn the mode ON and then again to turn o.
• In this mode, the drone will always move in the direction you press the Multi Directional Button no
matter which way the drone faces.
• To stop blades in case of an emergency.
When drone is in auto orientation mode, the drone will orient to the user (remote), no matter what direction
the drone is facing.
• Press the Orientation button. Remote will beep every 6 seconds to indicate it is in Auto Orientation mode.
• Push the right stick up will send the drone away from the user, push left will move left, etc.
• Press Auto Orientation button to exit mode.
Congratulations on your purchase of the LED Stunt Drone.
It’s time for some fun. This drone is capable of total controlled flight, fly
up/down, left/right, and pitch forward or backward, on 6 axis gyro stabilization
with a control range of 150 feet. Includes USB charging cable, replacement
blades and for auto orientation, auto take-o and auto landing control.
Included, is a 380 mAh Li-po drone battery. The remote controller requires
requires 3 AAA 1.5V batteries (not included). Alkaline batteries are
recommended.
Please read all instructions and warnings in this manual prior to using your
LED Stunt Drone, and keep this instruction manual as it contains important
information for future reference. Adult assembly and a Phillips screwdriver
will be required for battery installation.
Table of Contents
General Warnings Page 2
Contents Page 3
Remote Battery installation and Charging Battery Page 4
Replacing Propellers Page 5
Remote Overview Page 6
Operating Drone Page 7
Operating Page 8
Other Features Page 9
2 3
4 5
6 7
Sharper Image
®
name and logo (including the 77 logo) are trademarks or registered trademarks.
Distributed by and © 2020 MerchSource, LLC. Irvine, CA 92618. All rights reserved.
For customer support, please visit www.merchsource.com or call 1-800-374-2744.
The artwork and design of this manual are protected by US copyright law and may not be reproduced,
distributed, displayed, published or used for any purpose without prior written permission. It is not
permitted to alter, remove or reproduce any trademarks or copyright notice from this manual.
Printed in China
INSTRUCTION MANUAL
BATTERY WARNING:
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries.
• Insert batteries using the correct polarity. Do not short-circuit the supply terminal.
• Remove batteries when not in use. Recycle or dispose of exhausted batteries according to
federal, state, and local laws. Do not dispose of batteries in a fire - they may leak or explode.
• Only use manufacture specified battery(ies), charger(s) and/or adapter, if applicable,
specified by the manufacturer.
• Always use, replace, and recharge (if applicable) batteries under adult supervision.
KEEP THIS PACKAGING FOR REFERENCE AS IT CONTAINS IMPORTANT INFORMATION.
1. Slide open the remote’s battery
compartment.
2. Install 3 “AAA” batteries as shown in the
diagram above.
3. Replace and close battery compartment.
LED Drone
There is a risk of fire and personal injury if Li-Po battery is punctured, damage or misused.
• Never expose battery to extreme temperatures or moisture.
• Do not subject battery to strong impacts.
• Always keep battery away from flammable materials.
• Only use manufacture specified battery(ies), charger(s) and/or adapter, if applicable,
specified by the manufacturer.
• Battery is not serviceable.
• Let battery cool to room temperature before charging.
• While charging, never leave battery unattended.
• Recycle or dispose of battery according to federal, state and local laws.
KEEP THIS PACKAGING FOR REFERENCE AS IT CONTAINS IMPORTANT INFORMATION.
USB Charger Cable4 Replacement Propellers.
Note: The Battery Charger will light up when it is charging the battery
and turn o when the battery is fully charged.
1. Turn o the drone before charging.
2. Connect the battery charger cable to the charging port on the drone.
3. Connect USB connector to the power source.
• Only an adult should replace blades. To remove, pull up the blades directly.
• Replace propellers by following the diagram.
• Each blade spins dierently. Blade B spins counter clockwise and Blade A
spins clockwise.
1
Drone Controller
Step 4 - Lift O.
Step 5 - Operating Drone in Flight.
1. Follow this step if your drone
begins to drift during take o or
during flight.
A. Drone drifts backwards: Press
the Forward Trim Button.
B. Drone drifts forwards: Press the
Backwards Trim Button.
C. Drone drift right: Press the
Left Trim Button.
D. Drone drift left: Press the
Right Trim Button.
2. Use the Throttle Joystick
to increase or decrease your
elevation.
3. Use the Multi Directional
Joystick to move forwards,
backwards or side to side.
Step 6 - Landing Drone Step 7 - Retrieving Drone
1. Lower drone to 20 feet or less then press the Auto Land
button. Use the Multi Directional Joystick to maneuver drone. Or
Push the left joystick down until the drone landing.
2. In the event the blades will not stop spinning, you can perform
an emergency stop.
1. Turn o your remote by pressing the Power Button. This will
stop you from accidentally turning the propellers on.
2. Make sure the propellers have stopped spinning then pick up
your drone.
Note: You will need to pair your drone again before your next
flight, (part 1 of step 4).
Auto Orientation
Tips
• Do not crash drone into sand or dirt. Drone gears may become clogged.
• When first learning to fly, practice lifting o and hovering.
• Stay several feet from walls and buildings.
• Not recommended for children under 14 years of age. As with all electrical products, precautions should be
observed during handling and use to reduce the risk of electrical shock.
• Adult supervision is required at all times.
• Never fly drones above or near people, sudden changes in wind or other conditions could lead to
unexpected crashes.
• Always use caution when flying drone vehicles, obey relevant laws, respect the privacy and property rights
of others.
• The drone shall never be modified or used for anything except its intended purpose.
• Before each use, an adult should review the product and battery to determine that no damage or hazards exist.
• DO NOT TOUCH SPINNING PROPELLERS.
• Do not allow anything to intentionally make contact in any way with spinning propellers or prevent contact with
spinning blades by turning o remote prior to handling drone.
• Use caution and pay attention to your surroundings while operating drone.
• Do not fly drone into animals, people, or inanimate objects.
• Keep drone away from power lines, buildings, trees, public areas, and any other potentially hazardous areas.
• Do not operate in rain, heavy wind, and or any type of severe weather.
• Do not land drone on wet surfaces.
• Never touch or allow others to touch drone while it is flying.
• Always turn drone o when it is not in use.
• Always fly drone in large open areas.
SAFETY WARNINGS
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accord- ance with the
instructions, may cause harmful interference to radio communications. However there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Fly-aways are the responsibility of the individual pilot
and will not be replaced by the manufacturer.
1. Prepare for flight
• Drone must be charged before each use (Cable included).
• Indicator light on USB plug will turn o when fully charged.
• Install batteries in remote.
2. Pair your drone
Before each flight pair the remote with the drone:
1. Turn your drone on and place on a flat, level surface.
2. Turn on the remote.
3. Push the left stick up and then down.
4. Repeat steps 1 and 2 if necessary.
3. Calibrate
• Move both joysticks diagonally in toward the middle of the remote.
4. Remote Control Overview
Practice flying your drone below 10 feet and at low speeds until comfortable
with all controls to avoid unnecessary damage or injury.
• Left joystick: Up/Down controls elevation.
• Right joystick: controls flight direction.
• Direction Trim: Use to eliminate drift .
To cut power to drone, move left joystick to down position.
8
CHOKING HAZARD –
SMALL PARTS NOT FOR CHILDREN UNDER 3 YEARS.
ADULT ASSEMBLY REQUIRED.
9
4. Stunts - Press the Stunt
Button then press the Multi
Directional Joystick in the
direction you want to
complete a stunt.
Note:
1. The stunt function may be
disabled if the drone battery
power is low.
2. Hover the drone at or
above 10 feet before
attempting a stunt.
BB
A
A
A
A
B
B
5 FEET
10 FEET
Insert the USB
connector into a USB
power source
Insert the USB
connector into a USB
power source
Connect the battery
charger to drone
Connect the battery
charger to drone
AAA
AAA
AAA
Press the Auto Take o Button. Slowly and carefully press the
Throttle stick. Drone will begin
to elevate.
14+
OR
LIGHT
EFFECT
F TRIM
SPEED STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
LIGHT
EFFECT
F TRIM
SPEED STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
LIGHT
EFFECT
F TRIM
SPEED
STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
LIGHT
EFFECT
F TRIM
SPEED STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
LIGHT
EFFECT
F TRIM
SPEED STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
LIGHT
EFFECT
F TRIM
SPEED STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
LIGHT
EFFECT
F TRIM
SPEED
STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
LED STUNT DRONE
LED STUNT DRONE
BC
LIGHT
EFFECT
F TRIM
SPEED STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
ONOFF
LIGHT
EFFECT
F TRIM
SPEED STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
LIGHT
EFFECT
F TRIM
SPEED
STUNT
B TRIM
L TRIM
R TRIM
LAND
TAKE OFF
LIGHT
ON/OFF
EMERGENCY
STOP
AUTO
ORIENTATION
LED STUNT DRONE
INTRODUCTION
INTRODUCTION
GENERAL WARNINGS CONTENTS
REMOTE BATTERY INSTALLATION REPLACING PROPELLERS
REMOTE OVERVIEW OPERATING DRONE
OPERATING OTHER FEATURES
