User Manual

1 9
2 0
Instruction Mannual
58MM Portable MINI Thermal Printer
Step5:Once the Bluetooth printer is found. You can see it listed on the screen,
click “Next”
Step6:Choose “Let me choose my own passkey”, then enter “1234” ( this is
factory default passkey, if you want to change it, you have to inform us to
set the new passkey for you in our factory before shipping), then click “Next”.
Step7:if you can see the screen as below, that means the Bluetooth printer is
already connected. Please notice the assigned COM ports ,then Click”Finish”.
(Note: The Bluetooth device will automatically assign a COM port.)
Step8: Now if you want to test if the printer is OK to print, you could use a com
tool , and send printed data to Outgoing COM port( just as above image shown:
COM5).
(Com tool setting is 9600,N,8,1.)
1.Insert the CD-ROM,click on the file(58/80 series printer driver software )to
star to installation ,select the language appears as you need to install the
driver,as shown below:
9. USB port to be used
