Packing Content Please check whether the following items are present in the package. If any items missed or damaged, please contact your dealer. TABLE OF CONTENTS No. Description 1. FCC STATEMENT ....................................1 IMPORTANT INFORMATION ....................2 2. INTRODUCTION.......................................3 Quantity 1 RECON X5TX 1 2 RECON X5RX 1 3 Antenna 4 4 Connecting Plate 1 5 Remote Control 1 6 User’s Manual 1 3. SPECIFICATION...............................
RECON X5 BATTERY PLATE MODEL OVERVIEW RECON X5TX Operation Panel ｡ Power Switch with LED indicator Press to turn RECON X5TX on or off. The above LED indicator turns green when the power is on. ｡ LED Lights VIDEO LED lights up when RECON X5TX receives and transmits signal. LINK LED lights up when the signal link between RECON X5TX and RECON X5RX is established. Back Panel 1. SDI IN For SDI signal input 2. SDI OUT SDI signal loop out Power Interface 1.
RECON X5 MODULAR MODEL OVERVIEW RECON X5TX Operation Panel ｡ Power Switch with LED indicator Press to turn RECON X5TX on or off. The above LED indicator turns green when the power is on. ｡ LED Lights VIDEO LED lights up when RECON X5TX receives and transmits signal. LINK LED lights up when the signal link between RECON X5TX and RECON X5RX is established. Back Panel 1. SDI IN For SDI signal input 2. SDI OUT SDI signal loop out Power Interface 1.
Important Information Read this user’s manual carefully before use. It contains important information and notes regarding operating. The RECON X5 may not apply to the below cases: ｡ Repairs or product modification and alterations have been executed by unauthorized service personnel. ｡ Damages is caused by accidents including but not limited to lighting, water, fire, or moisture.
Installation For the Recon X5 systems with V or 3 Stus plates, you can simply mount the transmitter as you would a battery pack, positioning the TX between camera and battery. For those who have a modular system, please see the illustration to the right on how to “hard” mount the modular TX to the camera and coupling that with an optional Jetpack X power distribution module. Thank you for your choice in purchasing the Recon X5.
