User manual

Generating an annotated schema for Oracle 9i2
232 PowerDesigner
7 In the Extended Attributes page, type the name of a table or a column in
the Value column of the SQLName annotation, if you want to create a
table or a column from the selected element.
You can define a value for the following annotations:
Annotation Description
beanClassname Can be used within element declarations. If the element
is based on a global complexType, this name must be
identical to the beanClassname value within the
complexType declaration. If a name is specified by the
user, the bean generation will generate a bean class with
this name, instead of generating a name from the
element name
columnProps Specifies the column storage clause that is inserted into
the default CREATE TABLE statement. It is useful
mainly for elements that are mapped to tables, namely
top-level element declarations and out-of-line element
declarations
defaultTable Specifies the name of the table into which XML
instances of this schema should be stored. This is most
useful in cases when the XML is being inserted from
APIs where table name is not specified (for example,
FTP and HTTP)
