Defining dependencies
110
The link appears between the two objects.
Dragging a dependency to a different class
You can change the class at either end of a dependency by clicking
the dependency to select it, pressing down CTRL, and dragging one of
the attach points to a different class.
3 Click the Pointer tool in the palette toolbar.
or
Click the right mouse button.
You release the Dependency tool.
4 Double-click the new dependency in the model.
The dependency property sheet opens to the General page.
Opening property sheets at last accessed page
Property sheets open to the General page by default. However, you
can choose to open property sheets at the last page accessed by
selecting Tools➤Options➤Dialog, and selecting the option Keep
Last Tab in the Property Sheets groupbox.
5 Type a dependency name and a dependency code.
6 Select a stereotype from the dropdown listbox.
7 Click OK.
