Creating a realization
You can create a realization only from a class to an interface.
v To create a realization:
1 Click the Realization tool in the palette toolbar.
2 Drag the realization from the class to the interface.
The link appears between the two objects.
Dragging a realization to a different class
You can change the class or interface at either end of a realization by
clicking the realization to select it, pressing down CTRL, and dragging
one of the attach points to a different class or interface.
3 Click the Pointer tool in the palette toolbar.
or
Click the right mouse button.
You release the Realization tool.
4 Double-click the new realization in the model.
The realization property sheet opens to the General page.
