Opening a Rose model in an OOM
146
Objects imported
The following Rose objects are imported directly into the new OOM:
Package
Diagram
Class
Interface
Attribute
Operation
Generalization
Association
Dependency
Realization
Note
Note Link
Text
The import process translates some properties of imported objects into OOM
properties as follows:
Property in an Rose model Imported property in a OOM
Documentation Comment
Export Control - Implementation Visibility - Package
Property in an Rose model Imported property in a OOM
Cardinality - n Cardinality - *
Cardinality - 1..n Cardinality - 1..*
Property in an Rose model Imported property in a OOM
Virtual inheritance Virtual
Property in an Rose model Imported property in a OOM
Cardinality Multiplicity
Aggregate Container
Aggregate by reference, by
value, unspecified
Aggregation or Composition
All objects
Class
Generalization
Association
