Generating OOM objects to a CDM
When you generate a Conceptual Data Model (CDM) from an Object-
Oriented Model (OOM), PowerDesigner translates OOM objects and data
types to CDM objects and data types.
The current object language of an OOM has no effect on the generation to a
CDM.
Translating OOM objects into CDM objects
CDM generation translates OOM objects into conceptual objects.
OOM object CDM object after generation
Domain Domain
Class Entity (only if the Persistent and Generate checkboxes are
selected in the class property sheet)
Interface Not translated
Attribute Attribute
Identifier Identifier
Operation Not translated
Association Relationship or association
Dependency Not translated
Realization Not translated
Generalization Inheritance
