Chapter 6 Generating a Conceptual Data Model from an Object-Oriented Model
209
Generating a CDM from a package
To generate a CDM from a package, select the package name from
the Select Location dropdown listbox at the top of the page.
To generate CDM from a sub-package, select the Sub-Packages
Included tool next to the Selection Location dropdown listbox, and
then select a sub-package from the dropdown listbox.
8 Select checkboxes corresponding to each entity that you want to
generate.
9 Clear checkboxes corresponding to each entity that you do not want to
generate.
10 Click OK.
The Output window shows the progress of the generation process. The
new CDM appears in the diagram window.
