Object language editor categories
242
The following objects have existing default stereotypes that you can modify:
♦ Class
♦ Operation
♦ Generalization
♦ Dependency
♦ Realization
♦ Package
Class stereotypes
A class has the following default stereotypes:
Stereotype Description
actor Coherent set of roles
enumeration List of named values used as the range of a particular
attribute type
exception Exception class. Used mostly in relation to error
messages
implementationClass Class whose instances are statically typed, and that
defines the physical data structure and methods of a class
as implemented in traditional programming languages
process Heavyweight flow that can execute concurrently with
other processes
signal Specification of an asynchronous stimulus communicated
between instances
thread Lightweight flow that can execute concurrently with other
threads within the same process. Usually executes inside
the address space of an enclosing process
type Abstract class used only to specify the structure and
behavior of a set of objects, not the implementation
utility Class that has no instances
Default stereotypes
