Defining classes
34
Displaying text in class symbols
You can define the following display preferences for a class:
Preference Description
Show attributes Displays all the attributes of the class, or limits the number
displayed to a maximum that you specify in the Limit box
Show operations Displays all the operations of the class, or limits the number
displayed to a maximum that you specify in the Limit box
Show stereotypes When selected, displays the stereotype of the class
Show constraints When selected, displays the constraints (types of business
rule) that are attached to the class
You modify the display preferences for a class in the Display Preferences
dialog box.
v To modify the class display preferences:
1 Select Tools➤Display Preferences.
or
Right-click the diagram background and select Display Preferences from
the contextual menu.
The Display Preferences dialog box appears.
2 Expand the Object View node in the Category list.
3 Select Class.
