Installation Guide

Step 4
Connect hoses between
valves and spout
Non-
Removable Removable
position position
Step 5
Attach drain body to ange
Pipe
Sealant
Step 6
Install stopper and pivot rod
Step 7
Connect lift rod,
clevis strap, pivot rod
and adjust linkage
Step 8
Connect supply lines
(supply hoses not included)
HOT
COLD
Step 9
Flush lines and
check for leaks
Step 1
Attach control valves
Step 2
Attach handles
Step 3
Install lift rod & attach spout
Quick Install Guide Degas Widespread Lavatory Faucet, SLW-5412
Pipe
Sealant
Thread Locker
Included
Plumbers
Putty
 Need Help?
Contact Symmons customer service at
[phone], [phone]
Email: [e-mail]
Monday - Friday 7:30 am - 7:00 pm EST
 Please check Symmons website
for technical help, the latest product
information and warranty policy.
www.symmons.com/service
Tools & Materials
Installation and Service Instructions
Degas
™
Widespread Lavatory Faucet SLW-5412
Decorative Finish Code
Append to part numbers when applicable
-STN
Satin Nickel
-ORB
Oil Rubbed Bronze
--
Chrome (standard)
Model Number
SLW-5412......
Lavatory faucet with
pop-up drain
