www.ti.com
5.3 Peripheral Control Register (PCR)
SRIO Registers
The peripheral control register (PCR) contains a bit that enables or disables the entire peripheral and one
bit for every module within the peripheral where this level of control is desired. The module control bits can
only be written when the peripheral itself is enabled. In addition, the PCR has emulation control bits free
and soft, which control the peripheral behavior during emulation halts.
Figure 59. Peripheral Control Register (PCR)
31-16
Reserved
R-0x00
LEGEND: R = Read only; - n = value after reset
15-3 2 1 0
Reserved PERE SOFT FREE
N
R-0x00 RW- RW- RW-
0x00 0x00 0x01
LEGEND: R = Read only; - n = value after reset
Table 30. Peripheral Control Register (PCR) Field Descriptions
Bit Field Value Description
31-3 Reserved Reserved
2 PEREN Peripheral Enable. Controls the flow of data in the logical layer of the peripheral. As an initiator, it
will prevent TX transaction generation and as a target, it will disable incoming requests. This should
be the last enable bit to toggle when bringing the device out of reset to begin normal operation.
0b Disables data flow control
1b Enables data flow control
1 SOFT Emulation Control - SOFT bit
0 FREE Emulation Control - FREE bit
Serial RapidIO (SRIO)100 SPRU976 – March 2006
Submit Documentation Feedback
