www.ti.com
SRIO Registers
Table 31. Peripheral Settings Control Register (PER_SET_CNTL) Field Descriptions (continued)
Bit Field Value Description
17-15 TX_PRI1_WM Transmit credit threshold. Sets the required number of logical layer TX buffers needed to send
priority 1 packets across the UDI interface. This is valid for all ports in 1X mode only.
Required buffer count for transmit credit threshold 1 value TX_PRI1_WM:
• 000 → 8, 7, 6, 5, 4, 3, 2, 1
• 001 → 8, 7, 6, 5, 4, 3, 2
• 010 → 8, 7, 6, 5, 4, 3
• 011 → 8, 7, 6, 5, 4
• 100 → 8, 7, 6, 5
• 101 → 8, 7, 6
• 110 → 8, 7
• 111 → 8
14-12 TX_PRI0_WM Transmit credit threshold. Sets the required number of logical layer TX buffers needed to send
priority 0 packets across the UDI interface. This is valid for all ports in 1X mode only.
Required buffer count for transmit credit threshold 0 value TX_PRI0_WM:
• 000 → 8, 7, 6, 5, 4, 3, 2, 1
• 001 → 8, 7, 6, 5, 4, 3, 2
• 010 → 8, 7, 6, 5, 4, 3
• 011 → 8, 7, 6, 5, 4
• 100 → 8, 7, 6, 5
• 101 → 8, 7, 6
• 110 → 8, 7
• 111 → 8
11-9 CBA_TRANS_PR VBUS transaction priority. 000b – Highest Priority … 111b – Lowest Priority.
I
8 1X_MODE This register bit determines the UDI buffering setup (priority versus port).
0b UDI buffers are priority based
1b UDI buffers are port based. This mode must be selected when using more than one 1X port
7-4 PRESCALER_SE Internal frequency prescaler, used to drive the request to response timers. These 4 bits are the
LECT prescaler reload value allowing division of the DMA clock by a range from 1 up to 16. Setting
should reflect the device DMA frequency.
0000b Sets the internal clock frequency Min 44.7 and Max 89.5
0001b Sets the internal clock frequency Min 89.5 and Max 179.0
0010b Sets the internal clock frequency Min 134.2 and Max 268.4
0011b Sets the internal clock frequency Min 180.0 and Max 360.0
0100b Sets the internal clock frequency Min 223.7 and Max 447.4
0101b Sets the internal clock frequency Min 268.4 and Max 536.8
0110b Sets the internal clock frequency Min 313.2 and Max 626.4
0111b Sets the internal clock frequency Min 357.9 and Max 715.8
1000b sets the internal clock frequency Min 402.7 and Max 805.4
1001b Sets the internal clock frequency Min 447.4 and Max 894.8
1010b Sets the internal clock frequency Min 492.1 and Max 984.2
1011b Sets the internal clock frequency Min 536.9 and Max 1073.8
1100b Sets the internal clock frequency Min 581.6 and Max 1163.2
1101b Sets the internal clock frequency Min 626.3 and Max 1252.6
1110b Sets the internal clock frequency Min 671.1 and Max 1342.2
1111b Sets the internal clock frequency Min 715.8 and Max 1431.6
3 ENPLL4 Drives SERDES Macro 4 PLL Enable signal
0b Disables macro 4 PLL
1b Enables macro 4 PLL
