5.7 Block n Enable Register (BLK n_EN)
SRIO Registers
There are nine of these registers, one for each of nine logical blocks in the peripheral.
Figure 63. Block n Enable Register (BLK n_EN)
31-16
Reserved
R-0x00
LEGEND: R = Read only; - n = value after reset
15-1 0
Reserved EN
R-0x00 RW-
Undefi
ned
LEGEND: R = Read only; - n = value after reset
Table 34. Block n Enable Register (BLK n_EN) Field Descriptions
Bit Field Value Description
31-1 Reserved Reserved
0 EN Controls reset to nth (0 to 8) clock/logical domain.
0 Logical block n disabled (held in reset, clocks disabled)
1 Logical block n enabled
