www.ti.com
SRIO Registers
Table 43. SWING Bits
CFGTX[11:9] Amplitude (mV
dfpp
)
000 125
001 250
010 500
011 625
100 750
101 1000
110 1125
111 1250
Table 44. DE Bits
CFGTX[15:12] Amplitude Reduction
% dB
0000 0 0
0001 4.76 -0.42
0010 9.52 -0.87
0011 14.28 -1.34
0100 19.04 -1.83
0101 23.8 -2.36
0110 28.56 -2.92
0111 33.32 -3.52
1000 38.08 -4.16
1001 42.85 -4.86
1010 47.61 -5.61
1011 52.38 -6.44
1100 57.14 -7.35
1101 61.9 -8.38
1110 66.66 -9.54
1111 71.42 -10.87
SPRU976 – March 2006 Serial RapidIO (SRIO) 115
