5.15 SERDES Macro Configuration Register n (SERDES_CFG n_CNTL)
SRIO Registers
There are four of these registers, to support four ports.
Figure 71. SERDES Macros CFG (0-3) Registers (SERDES_CFG n_CNTL)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved LB Reserved MPY ENPLL
R-0 R/W-0 R-0 R/W-0 R/W-0
LEGEND: R = Read, W = Write, n = value at reset
Table 45. SERDES Macros CFG (0-3) Registers (SERDES_CFG n_CNTL) Field Descriptions
Bit Field Value Description
31:10 Reserved Reserved.
9:8 LB Loop bandwidth. Specify loop bandwidth settings.
00 Frequency dependent bandwidth. The PLL bandwidth is set to a twelfth of the frequency of
RIOCLK/ RIOCLK.
01 Reserved
10 Low bandwidth. The PLL bandwidth is set to a twentieth of the frequency of RIOCLK/ RIOCLK, or
3MHz (whichever is larger).
11 High bandwidth. The PLL bandwidth is set to a eighth of the frequency of RIOCLK/ RIOCLK.
7:6 Reserved Reserved.
5:1 MPY PLL multiply. Select PLL multiply factors between 4 and 60.
0000 4x
0001 5x
0010 6x
0011 Reserved
0100 8x
0101 10x
0110 12x
0111 12.5x
1000 15x
1001 20x
1010 25x
1011 Reserved
1100 Reserved
1101 50x
1110 60x
1111 Reserved
0 ENPLL Enable PLL. Enables the PLL.
