5.24 Error, Reset, and Special Event Status Interrupt Register (ERR_RST_EVNT_ICSR)
SRIO Registers
Figure 80. Error, Reset, and Special Event Status Interrupt Register (ERR_RST_EVNT_ICSR)
31-17 16
Reserved ICS16
R-0x00 R/W-
0x00
LEGEND: R = Read only; - n = value after reset
15-12 11 10 9 8 7-3 2 1 0
Reserved ICS11 ICS10 ICS9 ICS8 Reserved ICS2 ICS1 ICS0
R-0x00 R/W- R/W- R/W- R/W- R-0x00 R/W- R/W- R/W-
0x00 0x00 0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
Table 54. Error, Reset, and Special Event Status Interrupt Register (ERR_RST_EVNT_ICSR) Field
Descriptions
Bit Field Value Description
31-17 Reserved Reserved
16 ICS16 Device Reset Interrupt from any port
15-12 Reserved Reserved
11 ICS11 Port3 Error
10 ICS10 Port2 Error
9 ICS9 Port1 Error
8 ICS8 Port0 Error
7-3 Reserved Reserved
2 ICS2 Logical Layer Error Management Event Capture
1 ICS1 Port-write-in request received on any port
0 ICS0 Multi-cast event control symbol interrupt received on any port
