www.ti.com
5.26 DOORBELL n Interrupt Condition Routing Register (DOORBELL n_ICRR)
SRIO Registers
Each of the four doorbells is supported by a register of this type.
Figure 82. DOORBELL n Interrupt Condition Routing Register (DOORBELL n_ICRR)
31 28 27 24 23 20 19 16
ICR7 ICR6 ICR5 ICR4
R/W-0x00 R/W-0x00 R/W-0x00 R/W-0x00
15 12 11 8 7 4 3 0
ICR3 ICR2 ICR1 ICR0
R/W-0x00 R/W-0x00 R/W-0x00 R/W-0x00
LEGEND: R = Read, W = Write, n = value at reset
Table 56. DOORBELL n Interrupt Condition Routing Register (DOORBELL n_ICRR) Field
Descriptions
Bit Field Value Description
31-0 ICR (0-7) Doorbell n (0 to 3) CPU servicing interrupt condition routing bits
SPRU976 – March 2006 Serial RapidIO (SRIO) 127
