www.ti.com
5.37 Error, Reset, and Special Event Interrupt Condition Routing Register 2
SRIO Registers
(ERR_RST_EVNT_ICRR2)
Figure 93. Error, Reset, and Special Event Interrupt Condition Routing Register 2
(ERR_RST_EVNT_ICRR2)
31-16
Reserved
R-0x00
LEGEND: R = Read only; - n = value after reset
15-12 11-8 7-4 3-0
ICR11 ICR10 ICR9 ICR8
RW-0x00 RW-0x00 RW-0x00 RW-0x00
LEGEND: R = Read only; - n = value after reset
Table 67. Error, Reset, and Special Event Interrupt Condition Routing Register 2
(ERR_RST_EVNT_ICRR2) Field Descriptions
Bit Field Value Description
31-16 Reserved Reserved
15-12 ICR11 Port3 Error routing
11-8 ICR10 Port2 Error routing
7-4 ICR9 Port1 Error routing
3-0 ICR8 Port0 Error routing
Serial RapidIO (SRIO)138 SPRU976 – March 2006
