5.40 INTDST n Interrupt Rate Control Registers (INTDST n_RATE_CNTL)
SRIO Registers
There are eight of these registers.
Figure 96. INTDST n Interrupt Rate Control Registers (INTDST n_RATE_CNTL)
31-16
COUNT_DOWN_VALUE
RW-0x00
LEGEND: R = Read only; - n = value after reset
15-0
COUNT_DOWN_VALUE
RW-0x00
LEGEND: R = Read only; - n = value after reset
Table 70. INTDST n Interrupt Rate Control Registers (INTDST n_RATE_CNTL) Field Descriptions
Bit Field Value Description
31-0 COUNT_DOWN_ The rate at which an interrupt can be generated is controllable for each physical interrupt
VALUE destination. Rate control is implemented with a programmable down-counter. The counter reloads
and immediately starts down-counting each time the CPU writes these registers. Once the rate
control counter register is written, and the counter value reaches zero (note the CPU may write zero
immediately for a zero count), the interrupt pulse generation logic is allowed to fire a single pulse if
any bits in the corresponding ICSR register bits are set (or become set after the zero count is
reached).
