5.44 LSU n Control Register 3 (LSU n_REG3)
SRIO Registers
There are four of these registers, one for each LSU.
Figure 100. LSU n Control Register 3 (LSU n_REG3)
31-16
Reserved
R-0x00
LEGEND: R = Read only; - n = value after reset
15-12 11-0
Reserved BYTE_COUNT
R-0x00 RW-0x00
LEGEND: R = Read only; - n = value after reset
Table 74. LSU n Control Register 3 (LSU n_REG3) Field Descriptions
Bit Field Value Description
31-12 Reserved Reserved
11-0 BYTE_COUNT Number of data bytes to Read/Write up to 4KB. (Used in conjunction with RapidIO address to
create WRSIZE/RDSIZE and WDPTR in RapidIO packet header).
SPRU976 – March 2006 Serial RapidIO (SRIO) 145
Submit Documentation Feedback
