5.45 LSU n Control Register 4 (LSU n_REG4)
SRIO Registers
There are four of these registers, one for each LSU.
Figure 101. LSU n Control Register 4 (LSU n_REG4)
31-30 29-28 27-26 25-24 23-16
OUTPORTID PRIORITY XAMBS ID_SIZE DESTID
RW-0x00 RW-0x00 RW-0x00 RW-0x00 RW-0x00
LEGEND: R = Read only; - n = value after reset
15-8 7-1 0
DESTID Reserved INTER
RUPT
_REQ
RW-0x00 R-0x00 RW-
0x00
LEGEND: R = Read only; - n = value after reset
Table 75. LSU n Control Register 4 (LSU n_REG4) Field Descriptions
Bit Field Value Description
31-30 OUTPORTID Not applicable for Rapid IO header. Indicates the output port number for the packet to be
transmitted from. Specified by the CPU along with NodeID.
29-28 PRIORITY RapidIO prio field specifying packet priority. Request packets should not be sent at a priority level of
3 in order to avoid system deadlock. It is the responsibility of the software to assign the appropriate
outgoing priority.
27-26 XAMBS RapidIO xambs field specifying extended address MSB
25-24 ID_SIZE RapidIO tt field specifying 8 or 16bit DeviceIDs
00b 8 bit device Ids
01b 16 bit device Ids
23-8 DESTID RapidIO destinationID field specifying target device
7-1 Reserved Reserved
0 INTERRUPT_RE CPU controlled request bit used for interrupt generation. Typically used in conjunction with
Q Non-posted commands to alert the CPU when the requested data/status is present.
0b Interrupt is not requested upon completion of command
1b Interrupt is requested upon completion of command
