5.53 Transmit Queue Teardown Register (TX_QUEUE_TEAR_DOWN)
SRIO Registers
Figure 109. Transmit Queue Teardown Register (TX_QUEUE_TEAR_DOWN)
31-16
Reserved
R-0x00
LEGEND: R = Read only; - n = value after reset
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU
E15_T E14_T E13_T E12_T E11_T E10_T E9_TE E8_TE E7_TE E6_TE E5_TE E4_TE E3_TE E2_TE E1_TE E0_TE
EAR_ EAR_ EAR_ EAR_ EAR_ EAR_ AR_D AR_D AR_D AR_D AR_D AR_D AR_D AR_D AR_D AR_D
DWN DWN DWN DWN DWN DWN WN WN WN WN WN WN WN WN WN WN
W- W- W- W- W- W- W- W- W- W- W- W- W- W- W- W-
0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
Table 83. Transmit Queue Teardown Register (TX_QUEUE_TEAR_DOWN) Field Descriptions
Bit Field Value Description
31-16 Reserved Reserved
15 QUEUE15_TEAR Write = 1, tear down of Queue 15
_DWN
14 QUEUE14_TEAR Write = 1, tear down of Queue 14
_DWN
13 QUEUE13_TEAR Write = 1, tear down of Queue 13
_DWN
12 QUEUE12_TEAR Write = 1, tear down of Queue 12
_DWN
11 QUEUE11_TEAR Write = 1, tear down of Queue 11
_DWN
10 QUEUE10_TEAR Write = 1, tear down of Queue 10
_DWN
9 QUEUE9_TEAR_ Write = 1, tear down of Queue 9
DWN
8 QUEUE8_TEAR_ Write = 1, tear down of Queue 8
DWN
7 QUEUE7_TEAR_ Write = 1, tear down of Queue 7
DWN
6 QUEUE6_TEAR_ Write = 1, tear down of Queue 6
DWN
5 QUEUE5_TEAR_ Write = 1, tear down of Queue 5
DWN
4 QUEUE4_TEAR_ Write = 1, tear down of Queue 4
DWN
3 QUEUE3_TEAR_ Write = 1, tear down of Queue 3
DWN
2 QUEUE2_TEAR_ Write = 1, tear down of Queue 2
DWN
1 QUEUE1_TEAR_ Write = 1, tear down of Queue 1
DWN
0 QUEUE0_TEAR_ Write = 1, tear down of Queue 0
DWN
