5.54 Transmit CPPI Supported Flow Mask Registers n (TX_CPPI_FLOW_MASKS n)
SRIO Registers
There are eight registers of this type. See Figure 28 for more information on this register.
Figure 110. Transmit CPPI Supported Flow Mask Registers n (TX_CPPI_FLOW_MASKS n)
Transmit CPPI Supported Flow Mask Register 0 (TX_CPPI_FLOW_MASKS0)
31-16 15-0
QUEUE1_FLOW_MASK QUEUE0_FLOW_MASK
RW-0x01 RW-0x01
LEGEND: R = Read only; - n = value after reset
Transmit CPPI Supported Flow Mask Register 1 (TX_CPPI_FLOW_MASKS1)
31-16 15-0
QUEUE3_FLOW_MASK QUEUE2_FLOW_MASK
RW-0x01 RW-0x01
LEGEND: R = Read only; - n = value after reset
Transmit CPPI Supported Flow Mask Register 2 (TX_CPPI_FLOW_MASKS2)
31-16 15-0
QUEUE5_FLOW_MASK QUEUE4_FLOW_MASK
RW-0x01 RW-0x01
LEGEND: R = Read only; - n = value after reset
Transmit CPPI Supported Flow Mask Register 3 (TX_CPPI_FLOW_MASKS3)
31-16 15-0
QUEUE7_FLOW_MASK QUEUE6_FLOW_MASK
RW-0x01 RW-0x01
LEGEND: R = Read only; - n = value after reset
Transmit CPPI Supported Flow Mask Register 4 (TX_CPPI_FLOW_MASKS4)
31-16 15-0
QUEUE9_FLOW_MASK QUEUE8_FLOW_MASK
RW-0x01 RW-0x01
LEGEND: R = Read only; - n = value after reset
Transmit CPPI Supported Flow Mask Register 5 (TX_CPPI_FLOW_MASKS5)
31-16 15-0
QUEUE11_FLOW_MASK QUEUE10_FLOW_MASK
RW-0x01 RW-0x01
LEGEND: R = Read only; - n = value after reset
Transmit CPPI Supported Flow Mask Register 6 (TX_CPPI_FLOW_MASKS6)
31-16 15-0
QUEUE13_FLOW_MASK QUEUE12_FLOW_MASK
RW-0x01 RW-0x01
LEGEND: R = Read only; - n = value after reset
