5.56 Receive CPPI Control Register (RX_CPPI_CNTL)
SRIO Registers
Figure 112. Receive CPPI Control Register (RX_CPPI_CNTL)
31-16
Reserved
R-0x00
LEGEND: R = Read only; - n = value after reset
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU QUEU
E15_I E14_I E13_I E12_I E11_I E10_I E9_IN E8_IN E7_IN E6_IN E5_IN E4_IN E3_IN E2_IN E1_IN E0_IN
N_OR N_OR N_OR N_OR N_OR N_OR _ORD _ORD _ORD _ORD _ORD _ORD _ORD _ORD _ORD _ORD
DER DER DER DER DER DER ER ER ER ER ER ER ER ER ER ER
RW- RW- RW- RW- RW- RW- RW- RW- RW- RW- RW- RW- RW- RW- RW- RW-
0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
Table 86. Receive CPPI Control Register (RX_CPPI_CNTL) Field Descriptions
Bit Field Value Description
31-16 Reserved Reserved
15-0 QUEUE n_IN_OR Queue n In Order (QUEUE(0-15)_IN_ORDER)
DER (0-15)
0b Allows out-of-order message
1b Only allows in-order messages. Used for applications with dedicated source-destination flows.
