5.62 Mailbox-to-Queue Mapping Register H n (RXU_MAP_H n)
SRIO Registers
Figure 118. Mailbox-to-Queue Mapping Register H n (RXU_MAP_H n)
31-16
Reserved
R-0x00
LEGEND: R = Read only; - n = value after reset
15-10 9-8 7-6 5-2 1 0
Reserved TT Reserved QUEUE_ID PROM SEGM
ISCUO ENT_
US MAPPI
NG
R-0x00 RW-0x01 R-0x00 RW-0x00 RW- RW-
0x00 0x00
LEGEND: R = Read only; - n = value after reset
Table 92. Mailbox-to-Queue Mapping Register H n (RXU_MAP_H n) Field Descriptions
Bit Field Value Description
31-10 Reserved Reserved
9-8 TT Transport type
0b Matches the 8 LSB of the source ID
1b Matches the full 16 bits of the source ID
7-6 Reserved Reserved
5-2 QUEUE_ID Corresponding queue 0 to queue 15
1 PROMISCUOUS Promiscuous =1, full access to the queue for any source ID
0b Promiscuous bit enabled
1b Promiscuous bit disabled
0 SEGMENT_MAP Segment mapping
PING
0b Single segment: all six bits of mailbox valid
1b Multi segment: only 2 LSBs of mailbox valid
