5.63 Flow Control Table Entry Registers (FLOW_CNTL n)
SRIO Registers
There are sixteen of these registers.
Figure 119. Flow Control Table Entry Registers (FLOW_CNTL n)
31-18 17-16
Reserved TT
R-0x00 RW-0x01
LEGEND: R = Read only; - n = value after reset
15-0
FLOW_CNTL_ID
RW-0x00
LEGEND: R = Read only; - n = value after reset
Table 93. Flow Control Table Entry Registers (FLOW_CNTL n) Field Descriptions
Bit Field Value Description
31-18 Reserved Reserved
17-16 TT Selects Flow-Cntl-ID length
00b 8 bit Ids
01b 16 bit Ids
10b- Reserved
11b
15-0 FLOW_CNTL_ID DestID of Flow n
SPRU976 – March 2006 Serial RapidIO (SRIO) 165
