5.73 Local Configuration Space Base Address 1 CSR (LCL_CFG_BAR)
SRIO Registers
Figure 129. Local Configuration Space Base Address 1 CSR (LCL_CFG_BAR)
31-16
LCSBA
R-0x00
LEGEND: R = Read only; - n = value after reset
15-0
LCSBA
R-0x00
LEGEND: R = Read only; - n = value after reset
Table 103. Local Configuration Space Base Address 1 CSR (LCL_CFG_BAR) Field Descriptions
Bit Field Value Description
31-0 LCSBA For bit 31: Reserved for 34b addresses, bit 35 of a 50b address, bit 35 of a 66b address.
For bits 30 to 0: Bits 34-3 of a 34b address, bits 35-3 of a 50b address. bits 35-3 of a 66b address.
SPRU976 – March 2006 Serial RapidIO (SRIO) 175
