5.79 Port Response Time-Out Control CSR (SP_RT_CTL)
SRIO Registers
Figure 135. Port Response Time-Out Control CSR (SP_RT_CTL)
31-16
TIMEOUT_VALUE
RW-0xFFFFFF
LEGEND: R = Read only; - n = value after reset
15-8 7-0
TIMEOUT_VALUE Reserved
RW-0xFFFFFF R-0x00
LEGEND: R = Read only; - n = value after reset
Table 109. Port Response Time-Out Control CSR (SP_RT_CTL) Field Descriptions
Bit Field Value Description
31-8 TIMEOUT_VALU Timeout value for all ports on the device. This timeout is for sending a packet to receiving the
E corresponding response packet. Max value represents 3-6 seconds. The timeout duration can be
expressed as: Timeout = 15 * ((Prescale value + 1) * DMA clock period * Timeout Value); where
Prescale value is set in 0x0020 PSCR and the Timeout value is the decimal representation of this
register value. Example: 400Mhz DMA, Prescalar 0100b, Timeout Value FFFFFFh; Timeout
duration = 15*(4+1)*2.5nS*16777216 = 3.15s.
7-0 Reserved Reserved
