5.85 Port Control CSR n (SP n_CTL)
SRIO Registers
Each of the four ports is supported by a register of this type.
Figure 141. Port Control CSR n (SP n_CTL)
31-30 29-27 26-24 23 22 21 20 19 18-16
PORT_WIDTH INITIALIZED_PORT_WI PORT_WIDTH_OVERRI PORT OUTP INPUT ERRO MULTI Reserved
DTH DE _DISA UT_P _POR R_CH CAST
BLE ORT_ T_EN ECK_ _PAR
ENAB ABLE DISAB TICIP
LE LE ANT
R-0x01 R-0x00 RW-0x00 RW- RW- RW- RW- RW- R-0x00
0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
15-4 3 2 1 0
Reserved STOP DROP PORT PORT
_POR _PAC _LOC _TYPE
T_FLD KET_E KOUT
_ENC NABL
_ENA E
BLE
R-0x00 RW- RW- RW- R-
0x00 0x00 0x00 0x01
LEGEND: R = Read only; - n = value after reset
Table 115. Port Control CSR n (SP n_CTL) Field Descriptions
Bit Field Value Description
31-30 PORT_WIDTH Hardware width of the port (read only). Only 00b is valid for SP1, SP2, and SP3
00b Single-lane port
01b Four-lane port
10b-11b Reserved
29-27 INITIALIZED_PO Width of the ports after initialized (read only)
RT_WIDTH
000b Single-lane port, lane 0
001b Single-lane port, lane 2
010b Four-lane port
011b- Reserved
111b
26-24 PORT_WIDTH_O Soft port configuration to override the hardware size
VERRIDE
000b No override
001b Reserved
010b Force single lane, lane 0
011b Force single lane, lane 2
100b- Reserved
111b
23 PORT_DISABLE Port disable
0b Port receivers/drivers are enabled
1b Port receivers/drivers are disabled and are unable to receive/transmit to any packets or control
symbols
22 OUTPUT_PORT_ Output port enable
ENABLE
0b Port is stopped and not enabled to issue any packets except to route or respond to I/O logical
MAINTENANCE packets, depending upon the functionality of the processing element. Control
symbols are not affected and are sent normally.
1b Port is enabled to issue any packets
