5.88 Logical/Transport Layer Error Enable CSR (ERR_EN)
SRIO Registers
Figure 144. Logical/Transport Layer Error Enable CSR (ERR_EN)
31 30 29 28 27 26 25 24 23 22 21-16
IO_ERR_ MSG_E GSM_E ERR_MS ILL_TR ILL_TR MSG_RE PKT_R UNSOLICI UNSUP Reserved
RESP_EN RR_RE RR_RE G_FORM ANS_D ANS_T Q_TIMEO ESP_TI TED_RES PORTE
ABLE SP_EN SP_EN AT_ENAB ECODE ARGET UT_ENAB MEOU P_ENABL D_TRA
ABLE ABLE LE _ENAB _ERR_ LE T_ENA E NS_EN
LE ENABL BLE ABLE
E
RW-0x00 RW- RW- RW-0x00 RW- RW- RW-0x00 RW- RW-0x00 RW- R-0x00
0x00 0x00 0x00 0x00 0x00 0x00
LEGEND: R = Read only; - n = value after reset
15-8 7 6 5-0
Reserved RX_C RX_IO Reserved
PPI_S _SEC
ECURI URITY
TY
R-0x00 RW- RW- R-0x00
0x00 0x00
LEGEND: R = Read only; - n = value after reset
Table 118. Logical/Transport Layer Error Enable CSR (ERR_EN) Field Descriptions
Bit Field Value Description
31 IO_ERR_RESP_ENAB Enable reporting of an IO error response (endpoint device only). Save and lock original request
LE transaction capture information in all Logical/Transport Layer Capture CSRs.
30 MSG_ERR_RESP_EN Enable reporting of a Message error response. Save and lock transaction capture information in
ABLE all Logical/Transport Layer Capture CSRs. (endpoint device only)
29 GSM_ERR_RESP_EN Enable reporting of a GSM error response. Save and lock original request address in
ABLE Logical/Transport Layer Address Capture CSRs. Save and lock transaction capture information
in all Logical/Transport Layer Device ID and Control CSRs. (endpoint device only)
28 ERR_MSG_FORMAT_ Enable reporting of a message format error. Save and lock transaction capture information in
ENABLE Logical/Transport Layer Device ID and Control Capture CSRs. (endpoint device only)
27 ILL_TRANS_DECODE Enable reporting of an illegal transaction decode error. Save and lock transaction capture
_ENABLE information in Logical/Transport Layer Device ID and Control Capture CSRs. (switch or
end-point device)
26 ILL_TRANS_TARGET_ Enable reporting of an illegal transaction target error. Save and lock transaction capture
ERR_ENABLE information in Logical/Transport Layer Device ID and Control Capture CSRs. (endpoint device
only) NOT APPLICABLE – PACKET DESTROYED BEFORE REACHING LOGICAL LAYER.
25 MSG_REQ_TIMEOUT Enable reporting of a Message Request time-out error. Save and lock transaction capture
_ENABLE information in Logical/Transport Layer Device ID and Control Capture CSRs for the last
Message request segment packet received. (endpoint device only)
24 PKT_RESP_TIMEOUT Enable reporting of a packet response time-out error. Save and lock original request address in
_ENABLE Logical/Transport Layer Address Capture CSRs. Save and lock original request Destination ID
in Logical/Transport Layer Device ID Capture CSR. (endpoint device only)
23 UNSOLICITED_RESP_ Enable reporting of an unsolicited response error. Save and lock transaction capture
ENABLE information in Logical/Transport Layer Device ID and Control Capture CSRs. (switch or
end-point device)
22 UNSUPPORTED_TRA Enable reporting of an unsupported transaction error. Save and lock transaction capture
NS_ENABLE information in Logical/Transport Layer Device ID and Control Capture CSRs. (switch or
end-point device)
21-8 Reserved Reserved
7 RX_CPPI_SECURITY Enable reporting of attempt at unauthorized access to a RX queue. Save and Lock capture
information in appropriate Logical/Transport Layer Capture CSRs.
6 RX_IO_SECURITY Enable reporting of attempt at unauthorized memory location access. Save and Lock capture
information in appropriate Logical/Transport Layer Capture CSRs.
5-0 Reserved Reserved
